Manufacturer:Woodward
Product Number:5441-635
Product Type:Opto Isolator Module
Origin:USA
Dimensions:120 × 80 × 40 mm
Weight:0.25 kg
Views:37
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
The Woodward 5441-635 Opto Isolator Module is a specialized signal interface device designed to ensure reliable electrical isolation between high-voltage process control equipment and low-voltage logic systems. Built by Woodward, a global leader in industrial control and automation technology, the 5441-635 offers robust performance in harsh environments where signal protection, integrity, and noise immunity are critical.
This module plays a key role in industrial automation systems, where it acts as a protective barrier between control units and input/output signals, thus preventing electrical faults, voltage spikes, or ground loops from affecting the control logic. Utilizing opto-isolation technology, it converts incoming signals into light within the internal opto-coupler, thereby electrically isolating the input from the output.
The 5441-635 is commonly employed in Woodward control systems and can also be integrated into third-party automation platforms, making it a versatile choice in both retrofit and new system designs.
| Parameter | Details |
|---|---|
| Model Number | 5441-635 |
| Manufacturer | Woodward Inc. |
| Module Type | Opto Isolator Module |
| Function | Electrical isolation between control signal interfaces |
| Number of Channels | 8-channel (typical configuration) |
| Input Voltage Range | 5V to 32V DC (typical logic-level inputs) |
| Output Voltage | 5V/12V/24V DC compatible |
| Isolation Voltage | Up to 2500V RMS (input-to-output isolation) |
| Signal Type | Digital/logic signals (TTL, PLC I/O) |
| Response Time | < 1 ms |
| Input-Output Delay | Approx. 0.5 ms |
| LED Indicators | Yes, for signal and power status |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5% to 95% non-condensing |
| Power Consumption | Approx. 2 W |
| Mounting Type | Panel mount or DIN rail |
| Module Dimensions | 120 × 80 × 40 mm |
| Weight | 0.25 kg |
| Certifications | CE, UL, RoHS compliant |
The Woodward 5441-635 Opto Isolator Module is a crucial component in various industrial automation environments that require robust signal integrity and safety. Its use cases include:
Power Generation Systems – Isolation between generator sensors and turbine controllers.
Engine Control Panels – Protecting microprocessor-based controls from noisy field signals.
PLC/DCS Interfaces – Integrating third-party I/O with logic systems or SCADA systems.
Automated Test Equipment – Ensuring accurate signal transmission without electrical interference.
Oil & Gas Processing – Electrical signal separation in hazardous zone control environments.
Industrial Robotics – Safeguarding feedback and motion sensor lines from surges.
Superior Electrical Isolation: Provides protection against voltage transients, ground loops, and electrical faults.
High Noise Immunity: Excellent shielding from industrial electromagnetic interference (EMI).
Compact Design: Space-efficient construction suited for panel-mounted applications.
Enhanced Safety: Critical for protecting sensitive control systems in hazardous areas.
Universal Compatibility: Can be used with a wide range of industrial control and automation devices.
LED Diagnostics: Visual feedback for power and channel status ensures easy troubleshooting.
Q: What is the primary function of the 5441-635 module?
A: It provides opto-isolation between control signals, protecting logic systems from electrical noise or voltage spikes.
Q: Can this module be used with PLC systems?
A: Yes, it is commonly used to interface between field I/O and PLC/DCS logic controllers.
Q: What is the maximum isolation voltage?
A: The module can withstand up to 2500V RMS isolation between input and output.
Q: Does it support TTL-level input signals?
A: Yes, it supports standard logic levels including TTL, 5V, and 24V DC inputs.
Q: Is it suitable for high-speed signal transmission?
A: While not designed for ultra-high-speed applications, it supports sub-millisecond response suitable for industrial automation.
Q: How is the module mounted?
A: It supports both DIN rail and panel mounting for flexibility in cabinet layouts.
Q: Are LED indicators available for status checks?
A: Yes, the module includes LED indicators for signal activity and power status.
Q: Can it be used in marine or outdoor environments?
A: It’s designed for industrial indoor use. For marine or harsh outdoor conditions, use in a weather-protected enclosure.
Q: Does it require any special configuration software?
A: No, it functions as a passive interface and does not require programming.
Q: Is it hot-swappable?
A: While physically replaceable during operation, isolation circuit integrity should be verified before hot-swapping in live systems.
