The GE Fanuc IC693CHS398J is a 5-slot expansion base for the GE Series 90-30 Programmable Logic Controller (PLC) system. It allows for the addition of I/O and option modules, expanding the PLC’s capabilities in industrial automation systems. With its durable construction and simple installation process, this expansion base ensures a robust and flexible solution for various control applications.

Technical Specifications

• Model Number: GE Fanuc IC693CHS398J
• Type: Expansion Baseplate
• Number of Slots: 5
• Dimensions: 10.43 x 5.12 x 5.59 inches (W x H x D)
• Weight: 1.15 lbs
• Internal Power Used: 170 mA @ 5 VDC
• Connection Type: 25-pin female D-type Expansion connector for interconnecting baseplates
• Rack Number Selection: DIP switch to select rack number during installation
• Maximum Cable Length: 50 feet between CPU baseplate and expansion baseplates
• Maximum Remote Baseplates:
  • 4 for CPUs 331, 340, and 341
  • 7 for CPUs 350 and higher
