GE Fanuc IC693MDL753A Discrete Output Module

The GE Fanuc IC693MDL753A is a versatile discrete output module designed for the Series 90-30 programmable logic controller (PLC). It allows the PLC to control external devices such as motors, valves, alarms, and lights by providing 32 individual output points. These outputs are grouped into four isolated sections, each with its own dedicated common connection. The module operates with a positive logic configuration, meaning a high signal triggers the output. It supports a wide voltage range of 12 to 24 VDC and is capable of handling 0.5A of output current per point.

Technical Specifications

• Voltage: 12 to 24 VDC
• Output Voltage Range: 10.2 to 28.8 VDC
• Number of Outputs: 32 (divided into 4 groups of 8 outputs)
• Output Current: 0.5 A per point, 4 A per module
• Power Consumption: 111 mA from the power supply in the BIU
• Protection: 5 Amp fuse for each output point
• Dimensions: 8.83″ x 3.50″ x 3.94″ (22.44 cm x 8.89 cm x 10.00 cm)
• Weight: 0.5 kg
• Operating Temperature Range: 0°C to 50°C (32°F to 122°F)
• Relative Humidity: 5% to 95%, non-condensing
• Isolation: 1500 V between field side and logic side
• Inrush Current: 0.3 VDC
• On-state Voltage Drop: 0.3 VDC
