ABB Bailey NDSI01 6635905A1 Digital Slave Input Module

The ABB Bailey NDSI01 6635905A1 Digital Slave Input Module is a high-performance discrete input module engineered for use within the INFI 90 Distributed Control System (DCS). Designed for precise acquisition of digital signals from the field, this module reads the status of various discrete sensors and switchgear components and communicates their condition to the controller in real-time.

With 16 isolated digital input channels, the NDSI01 is capable of monitoring contacts such as limit switches, push buttons, interlocks, relays, and auxiliary feedback points. It supports fail-safe operations and ensures reliability in the face of voltage spikes and industrial electrical noise, making it a dependable part of control infrastructures in process industries.

This module is widely used in industrial plants for signal collection in mission-critical applications, such as emergency stop systems, valve limit detection, and motor starter feedback. Built with rugged construction and diagnostic capabilities, the NDSI01 is a cornerstone in Bailey’s proven control solutions portfolio.

Technical Specifications

Product Applications

The NDSI01 module is suitable for a wide range of industrial applications where accurate monitoring of binary input conditions is essential. Its use spans various sectors including:

• Power Generation

  Tracks circuit breaker status, auxiliary relay contacts, and turbine protection inputs.

• Oil & Gas Industry

  Monitors emergency shutdown pushbuttons, wellhead equipment signals, and flow switch statuses.

• Chemical & Petrochemical Plants

  Used for limit switch monitoring, tank overflow switches, and critical interlock signal acquisition.

• Metals and Mining

  Detects conveyor belt sensors, proximity switches, and safety interlocks.

• Water & Wastewater Treatment

  Monitors pump feedback, valve position sensors, and level indicators.

• Pulp & Paper Industry

  Inputs from feeder interlocks, emergency pull cords, and stop switches are collected through NDSI01.

Product Advantages

1. Reliable Signal Acquisition

   Delivers accurate digital signal monitoring for critical applications under industrial stress conditions.

2. High-Density Input

   Features 16 input channels per module, optimizing rack space and reducing system complexity.

3. LED Indicators

   Channel-specific LEDs provide clear diagnostics and signal presence confirmation.

4. Noise Immunity

   Designed with electrical isolation and surge protection to function reliably in harsh EMI conditions.

5. Flexible Input Support

   Compatible with both dry contacts and logic voltage levels.

6. Industrial-Grade Durability

   Built to operate under extreme environmental conditions with extended temperature and humidity tolerance.

7. Seamless DCS Integration

   Fully compatible with ABB Bailey INFI 90 systems, ensuring no compatibility or software adaptation issues.

8. Extended Life Cycle

   Backed by ABB’s support for legacy systems, ideal for facilities with long system life expectations.

9. Easy Maintenance

   LEDs and diagnostic tools assist in quick fault isolation and system health checks.

10. Proven Performance

    Trusted by thousands of industrial sites globally in 24/7 operation.
