ABB GFD233A 3BHE022294R0101 Analog Input Module

The ABB GFD233A 3BHE022294R0101 is an analog input module designed specifically for the ABB MEGADRIVE® LCI system. It serves to convert analog voltage and current signals into digital signals processed by the LCI controller. With its versatile configuration options, the module supports both single-ended and differential operation across its eight analog input channels. Additionally, it includes two analog output channels capable of generating precise analog control signals.

Technical Specifications

• Number of Analog Input Channels: 8
• Analog Input Range: -10 V to +10 V
• Analog Input Resolution: 16 bits
• Analog Input Accuracy: ±0.1% of full scale
• Number of Analog Output Channels: 2
• Analog Output Range: -10 V to +10 V
• Analog Output Resolution: 16 bits
• Analog Output Accuracy: ±0.1% of full scale
• Power Supply: 24 VDC
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Dimensions: 100 mm x 60 mm x 30 mm
• Weight: 200 g

Applications

The ABB GFD233A 3BHE022294R0101 finds application in various fields, including:

• Process control
• Machine control
• Building automation
• Test and measurement

Additional Information

• The module is compatible with all MEGADRIVE® LCI controllers.
• It can be mounted on a DIN rail or directly into a panel.
• Features a screw terminal block for straightforward wire connection.
• CE certified and RoHS compliant.
