Honeywell CC-TCNT01 51308307-175 C300 Controller Backplane

The Honeywell CC-TCNT01 51308307-175 is a Network Interface Module (NIM) designed for integration within Honeywell’s Experion Process Knowledge System (PKS) and C300 controller infrastructure. It serves as a communication interface, enabling seamless data exchange between the control system and the network backbone. This module supports high-speed deterministic communications and provides robust integration capabilities for distributed control applications in demanding industrial environments such as refining, power generation, petrochemical, and chemical processing.

Built with industrial-grade reliability, the CC-TCNT01 ensures the high availability and fault tolerance required for modern process automation. It is engineered to manage real-time data, reduce network latency, and integrate seamlessly into Honeywell’s Fault Tolerant Ethernet (FTE) architecture.

Technical Specifications

Product Applications

The Honeywell CC-TCNT01 51308307-175 is extensively used across various industries that require high-reliability control and communication infrastructure:

• Oil & Gas Processing Plants

• Power Generation Facilities

• Chemical and Petrochemical Industries

• Pulp and Paper Manufacturing

• Water Treatment Plants

• Pharmaceutical Production Systems

Its ability to integrate seamlessly with C300 controllers makes it ideal for real-time automation and secure data transmission across distributed systems.

Product Advantages

• Fault-Tolerant Design: Supports dual Ethernet connections, ensuring redundancy and communication continuity.

• High Availability: Critical for industries that require 24/7 operation and fail-safe communication.

• Seamless Integration: Native compatibility with Honeywell’s C300 controllers and Experion PKS.

• Compact Size: Designed for space-efficient DIN rail mounting.

• Long Lifecycle: Industrial-grade components ensure durability and extended operational life.

• Reduced Downtime: Hot-swap capabilities and redundancy improve maintenance efficiency.

• Security Support: Meets modern security standards to protect process networks.

FAQ

Q1: What is the main function of the CC-TCNT01 module?

A1: It acts as a network interface for C300 controllers, facilitating communication over Fault Tolerant Ethernet networks.

Q2: Can the CC-TCNT01 be used in non-Honeywell systems?

A2: It is specifically designed for Honeywell Experion systems and is not intended for third-party systems.

Q3: How many Ethernet ports are available on this module?

A3: It has two RJ-45 Ethernet ports to support redundant FTE connections.

Q4: Is the CC-TCNT01 hot-swappable?

A4: Yes, the module can be replaced without shutting down the entire system.

Q5: Does the CC-TCNT01 support diagnostics?

A5: Yes, it includes built-in diagnostics for communication and health status monitoring.

Q6: What is the rated voltage or power input?

A6: It is powered through the backplane of the controller, typically consuming less than 5 W.

Q7: How does the CC-TCNT01 enhance system reliability?

A7: Through dual Ethernet ports, it ensures communication continuity in case one network path fails.

Q8: Can it operate in outdoor or harsh environments?

A8: It is designed for industrial use with a wide temperature range but must be housed in protective enclosures.

Q9: Is firmware upgradeable?

A9: Yes, firmware updates are supported via Honeywell tools to improve functionality or security.

Q10: How do I confirm compatibility with my control system?

A10: Compatibility is assured with Honeywell’s Experion PKS and C300 systems; check system revision levels in documentation.
