ABB Bailey IPFAN13 Fan Module

The ABB Bailey IPFAN13 is a high-efficiency Fan Module specifically designed for thermal management within ABB’s INFI 90 or Symphony DCS system enclosures. As a critical component in industrial control cabinets, the IPFAN13 ensures that heat-sensitive modules such as CPUs, power supplies, and I/O boards operate within their safe thermal limits by maintaining steady airflow and proper temperature distribution.

The fan module is engineered to integrate directly with ABB Bailey’s system chassis and features reliable connectors, durable housing, and consistent fan performance over extended operation periods. Whether installed in harsh environments or mission-critical control rooms, the IPFAN13 provides the active cooling support essential for maintaining system uptime and extending the lifespan of automation hardware.

Product Specifications

Product Applications

The ABB IPFAN13 Fan Module is primarily utilized in industrial control environments where ABB’s INFI 90 or Symphony series systems are deployed. Applications include:

• Distributed Control System (DCS) Cabinets – Prevents overheating of I/O and CPU cards.

• Power Plants & Utilities – Maintains optimal operating temperature in long-term critical systems.

• Oil & Gas Facilities – Used in process control rooms where thermal buildup is a risk.

• Manufacturing Automation Systems – Ensures ventilation for high-speed processors and PLC cards.

• Water and Wastewater Treatment Plants – Installed in dusty or humid environments to maintain system reliability.

• Chemical and Pharmaceutical Plants – Preserves thermal balance in cleanroom-compliant enclosures.

Product Advantages

• Optimized for ABB Systems: Purpose-built for ABB INFI 90 and Symphony systems, ensuring maximum compatibility.

• Reliable Airflow: Maintains continuous, directed airflow to avoid heat concentration around active modules.

• Long Service Life: High-grade fan bearings and motor construction allow>50,000 hours of runtime.

• Quiet Operation: Operates below 45 dB, ideal for use in control rooms and noise-sensitive environments.

• Compact Form Factor: Small yet powerful—ideal for installations with tight space constraints.

• Easy Replacement: Modular design supports quick swap during maintenance without rewiring.

• Low Power Draw: Efficiently designed to minimize power consumption, contributing to energy savings.

• Durable Construction: Industrial-grade casing and connectors resist shock, vibration, and corrosion.

• Plug-and-Play Setup: Ships ready for immediate integration into ABB system backplanes.

• Supports Uptime: Extends the lifespan of all surrounding modules by regulating temperature effectively.

Frequently Asked Questions (FAQ)

1. What is the purpose of the IPFAN13 module?

   It provides active cooling for ABB INFI 90/Symphony systems to prevent overheating of critical control components.

2. Is this fan module compatible with third-party systems?

   It is specifically designed for ABB systems and not recommended for non-ABB control racks.

3. Can I replace the fan without shutting down the entire cabinet?

   Yes, the IPFAN13 is modular and can be replaced during maintenance windows with minimal downtime.

4. How noisy is the IPFAN13 during operation?

   It operates at a noise level below 45 dB, which is considered quiet for industrial standards.

5. What kind of power source does the module require?

   It operates on 24 VDC, which is standard for ABB system control power buses.

6. Does the fan module include temperature sensors?

   The base model does not include onboard temperature sensors, but compatible systems may support them.

7. What is the expected lifespan of this fan?

   The MTBF (Mean Time Before Failure) is rated above 50,000 hours under nominal conditions.

8. Is it resistant to dust or moisture?

   Yes, it is built for industrial use and operates reliably in high-humidity and dusty environments.

9. How do I know when the fan needs replacement?

   Most ABB systems monitor internal temperatures and can trigger alerts when cooling is insufficient.

10. Where is this product manufactured?

    The IPFAN13 is manufactured in the Sweden.
