Honeywell MU-TPIX12 51304084-100 Pulse Input Field Termination Assembly

The Honeywell MU-TPIX12 51304084-100 Pulse Input Field Termination Assembly is an industrial-grade component designed to interface pulse signals from field devices to Honeywell’s process control and safety systems. It ensures high-integrity signal transmission for accurate, real-time data acquisition essential to critical industrial operations.

This assembly efficiently collects pulse inputs from devices such as flow meters, speed sensors, or tachometers. Its reliable design enhances system performance, signal protection, and simplifies installation within Honeywell’s Experion PKS and Safety Manager platforms.

Key Features

• Dedicated termination assembly for pulse signal inputs.

• Supports high-speed pulse signal acquisition up to 20 kHz.

• Galvanic isolation for signal and equipment protection.

• Optimized for seamless integration with Honeywell control systems.

• Robust, durable design suitable for demanding environments.

• Compact form factor for efficient use of panel space.

• Reliable screw terminals for secure field wiring.

• Low-maintenance with extended operational life.

• High noise immunity ensuring signal integrity.

• Suitable for diverse pulse signal applications across industries.

Technical Specifications

Industry Applications

• Oil & Gas: Interfaces with flow meters and speed sensors in pipelines and processing facilities.

• Chemical Processing: Pulse input acquisition for precise flow measurement and rotating equipment monitoring.

• Power Generation: Pulse signal reception from turbines, motors, and speed monitoring devices.

• Water & Wastewater: Integration with flow and dosing equipment for accurate process control.

• Pharmaceutical Production: Supports batching, dispensing, and flow verification systems.

• Food & Beverage: Enables real-time pulse signal collection from production line measurement devices.

Product Advantages

• Accurate Signal Acquisition: Provides reliable pulse input processing for improved measurement and control.

• Durable Industrial Design: Engineered to withstand harsh environments with high durability.

• Seamless System Integration: Fully compatible with Honeywell DCS and SIS platforms.

• Enhanced Electrical Isolation: Galvanic isolation safeguards equipment and personnel.

• Compact, Space-Saving Assembly: Easy installation even within constrained control cabinets.

• Minimal Maintenance: Long lifecycle and robust construction reduce service requirements.

• Broad Application Flexibility: Accommodates a wide variety of pulse-generating devices.

• Improved System Reliability: Ensures uninterrupted signal transmission critical to operations.

Frequently Asked Questions (FAQ)

1. What does the MU-TPIX12 51304084-100 do?

   It functions as a pulse input field termination assembly, transmitting pulse signals from field devices to control systems.

2. Which Honeywell systems work with MU-TPIX12?

   It integrates with Honeywell Experion PKS and Safety Manager systems.

3. What pulse frequency range does it support?

   It can handle pulse signals up to 20 kHz.

4. Is there channel isolation?

   Yes, it features channel-to-channel and channel-to-ground galvanic isolation.

5. What type of field devices connect to it?

   Compatible with pulse-generating devices such as flow meters, speed sensors, and tachometers.

6. Can it withstand harsh environments?

   Yes, it operates reliably between -20°C to +60°C and up to 95% humidity.

7. Is installation complicated?

   No, its compact design and screw terminals allow straightforward installation.

8. Does it require regular maintenance?

   Minimal maintenance is needed due to its robust, durable construction.

9. Are there certifications?

   Yes, it is CE, UL, and FM certified for industrial use.

10. Can it be replaced without significant downtime?

    Yes, it can be replaced during scheduled maintenance with minimal operational disruption.
