General Electric IC660EBA024 I/O Thermocouple Input Block Electronics Assembly

The GE IC660EBA024 I/O Thermocouple Input Block Electronics Assembly is a highly reliable and efficient module designed to handle temperature input signals from various types of thermocouples. This component is part of GE’s 90-30 I/O system and offers seamless integration with GE PLCs (Programmable Logic Controllers), making it an essential part of industrial automation and process control systems. The module is engineered to convert thermocouple signals into an electrical output that can be processed by control systems, providing accurate temperature measurement and monitoring.

It supports a broad range of thermocouple types, ensuring its versatility in various industries that require precise temperature monitoring. From manufacturing to energy production, the IC660EBA024 can handle the toughest environmental conditions and deliver reliable performance. Its robust design, flexibility, and ease of integration make it a trusted solution in industrial control systems worldwide.

Product Parameters

The following table outlines the key technical specifications of the GE IC660EBA024 I/O Thermocouple Input Block Electronics Assembly:

Applications

The GE IC660EBA024 I/O Thermocouple Input Block Electronics Assembly is designed for use in systems that require precise and reliable temperature measurements. It is well-suited for industries that rely on thermocouples for temperature input and process control.

Key Applications:

• Process Control Systems: The module is used in industries such as oil and gas, chemical processing, and power generation, where accurate temperature measurement is crucial for system control and safety.

• Manufacturing Automation: The IC660EBA024 is ideal for monitoring temperature in automated manufacturing systems, helping ensure optimal operating conditions and maintaining product quality.

• Environmental Monitoring: It is used in environmental monitoring systems, such as laboratories and research facilities, to measure temperature variations and ensure precise data collection.

• HVAC Systems: In heating, ventilation, and air conditioning systems, the module is used to monitor temperature, improving system efficiency and ensuring safety.

• Power Generation: The module plays an important role in power plants and energy production facilities, enabling real-time temperature monitoring to maintain efficiency and prevent system failures.

Advantages

The GE IC660EBA024 I/O Thermocouple Input Block Electronics Assembly offers numerous advantages that make it an ideal choice for temperature monitoring in industrial settings:

1. Wide Compatibility: Supports a variety of thermocouple types, including J, K, T, E, R, S, B, N, L, and U, making it adaptable to different industrial applications.

2. High Accuracy: The module provides a high level of accuracy with ±0.25% of full-scale precision, ensuring reliable and precise temperature measurements.

3. Temperature Range Flexibility: With an input range of -200°C to 1820°C, the IC660EBA024 is suitable for a broad range of industrial environments.

4. Robust Construction: Built to withstand harsh conditions, the module operates reliably in extreme temperatures ranging from -40°C to +85°C, making it perfect for industrial settings.

5. Compact Design: Its compact dimensions (224.4 x 88.9 x 100 mm) allow for easy integration into existing systems, saving valuable space in control cabinets.

6. Signal Conditioning: The module provides linearization and filtering to ensure accurate signal conversion, reducing measurement errors and improving overall system performance.

7. Energy Efficient: Operating at 5V DC with minimal power consumption, the IC660EBA024 is an energy-efficient solution for temperature monitoring.

8. Flexible Mounting: Can be mounted on a DIN rail or directly on equipment, providing flexibility in system configuration and installation.

9. Reliable Communication: It integrates easily with GE Series 90-30 PLC systems, offering efficient data transfer and control within automated systems.

10. Cost-effective: Offering high-quality performance at a reasonable price, the IC660EBA024 provides an excellent balance of cost and reliability for temperature monitoring applications.

FAQ

1. What types of thermocouples does the IC660EBA024 support?

   • The module supports thermocouples of types J, K, T, E, R, S, B, N, L, and U.

2. What is the operating temperature range for this module?

   • The module operates within a temperature range of -40°C to +85°C, making it suitable for harsh industrial environments.

3. How accurate is the GE IC660EBA024?

   • The module offers an accuracy of ±0.25% of full scale, ensuring reliable and precise measurements.

4. What is the input range of the IC660EBA024?

   • The input range for the module is from -200°C to 1820°C, allowing for diverse temperature monitoring applications.

5. What is the power supply requirement for this module?

   • The IC660EBA024 requires a 5V DC ±10% power supply to operate.

6. What are the dimensions of the module?

   • The module measures 224.4 x 88.9 x 100 mm.

7. What is the weight of the IC660EBA024?

   • The module weighs 1.8 kg, making it lightweight and easy to integrate into control panels.

8. Can the IC660EBA024 be used with other GE PLC systems?

   • Yes, the IC660EBA024 is compatible with GE Series 90-30 PLC systems.

9. What is the resolution of the analog input?

   • The module provides a 12-bit resolution for accurate temperature measurements.

10. How is signal conditioning handled by this module?

    • The module provides linearization and filtering to ensure accurate signal conversion and prevent errors in temperature readings.
