ABB PM564-T 1TNE968900R1100 Prog Logic Controller

The ABB PM564-T (1TNE968900R1100) is a powerful and compact Programmable Logic Controller (PLC) belonging to ABB’s AC500-eCo series, designed for cost-effective, modular automation solutions in both discrete and process industries. This CPU module offers integrated I/O, Ethernet communication, and user-friendly programming via Automation Builder, making it a popular choice for small to medium-sized control applications.

The PM564-T is suitable for stand-alone control or as part of a scalable distributed system. It offers reliable performance, wide protocol support, and long-term availability, allowing OEMs and end users to build flexible automation architectures with confidence. Its robust design makes it ideal for machine builders, building automation, water/wastewater, and more.

Product Specifications

Applications

The PM564-T is ideal for compact control applications that demand reliable performance, communication capability, and flexibility within tight space and budget constraints:

• OEM Machine Automation

  Used in packaging, conveying, textile, and woodworking machines.

• Building Automation

  Controls HVAC systems, lighting, access control, and energy monitoring.

• Water & Wastewater Management

  Suitable for pump control, filtration systems, tank monitoring, and level regulation.

• Material Handling Systems

  Automates conveyors, lifts, sorters, and warehouse management equipment.

• Renewable Energy Systems

  Manages solar inverters, wind turbine subsystems, and data logging.

• Agricultural and Irrigation Systems

  Controls valve operations, irrigation timing, and climate monitoring in greenhouses.

Product Advantages

• Compact All-in-One Design

  Integrates CPU, I/O, and communication in one small footprint, reducing panel space.

• Affordable and Scalable

  Entry-level cost with expansion options to match growing automation needs.

• Flexible Communication

  Built-in Ethernet and serial ports allow easy integration with SCADA and HMI systems.

• IEC 61131 Compliant Programming

  Supports structured text, ladder logic, and function block diagram programming via Automation Builder.

• High Noise Immunity

  Designed to operate reliably in harsh electrical environments.

• Industrial-Grade Reliability

  Proven design for continuous 24/7 operation in industrial settings.

• Fast Commissioning

  Quick setup using intuitive engineering tools and configuration wizards.

Frequently Asked Questions (FAQ)

1. What is the primary use of the PM564-T?

   It is a programmable controller used to automate and control machinery or processes in small to mid-sized systems.

2. Can I expand the I/O on the PM564-T?

   Yes, it supports expansion via AC500-eCo I/O modules.

3. Which programming environment is used for PM564-T?

   It is programmed using ABB Automation Builder, which is based on CoDeSys.

4. Does the unit support Modbus communication?

   Yes, it supports both Modbus TCP and Modbus RTU protocols.

5. Is there a real-time clock onboard?

   Yes, it includes a real-time clock with optional battery backup for time-sensitive applications.

6. Can I connect the PLC to an HMI or SCADA system?

   Absolutely. Ethernet and serial interfaces make it compatible with most HMI/SCADA platforms.

7. Is the unit suitable for harsh environments?

   While the unit is rugged, it should be installed in a protected control cabinet.

8. Can this PLC operate standalone?

   Yes, the PM564-T can function independently or as part of a distributed system.

9. How do I perform firmware updates?

   Firmware updates are performed via USB or Ethernet using ABB’s configuration tools.

10. Is it suitable for beginners in PLC programming?

    Yes, it is user-friendly and ideal for both educational and industrial environments.
