Honeywell 900B16-0001 HC900 Analog Output Module

The Honeywell 900B16-0001 is a 16-channel Analog Output Module developed for use within the HC900 Hybrid Controller platform, which combines the power of process control, logic control, and data acquisition into a single, scalable automation solution. This module is a high-performance, compact analog output unit specifically engineered for demanding industrial environments, where precise analog control outputs are critical to process efficiency and safety.

Designed to deliver accurate current-based output signals, the 900B16-0001 enables seamless control of actuators, valves, I/P transducers, and other field instrumentation. With 16 isolated analog output channels, it is ideal for applications that require dense I/O configurations without compromising on signal integrity or system robustness. The module integrates tightly with the HC900 CPU through the backplane and is configured using Honeywell’s Control Designer software, ensuring a user-friendly setup and maintenance process.

By combining rugged industrial design, high-resolution output, and diagnostic capabilities, the Honeywell 900B16-0001 stands as a dependable solution in the realm of analog output modules, delivering performance, flexibility, and reliability across a wide range of process control systems.

Product Specifications

Applications

The Honeywell 900B16-0001 Analog Output Module is extensively deployed in industrial environments where precise analog output is essential. Its high-density 16-channel design and robust performance make it suitable for:

• Chemical Manufacturing: Delivering continuous analog control signals to process valves and dosing pumps.

• Power Generation: Controlling feedwater, steam valves, and auxiliary systems in turbine regulation.

• Oil and Gas Facilities: Operating I/P converters and modulating valves in pipeline control systems.

• Food and Beverage: Regulating temperature, pressure, and flow in automated production lines.

• Water/Wastewater Treatment: Sending analog control signals to variable speed drives and valve actuators.

• Pharmaceutical Production: Managing batch processes requiring precise analog output for validated systems.

• OEM Industrial Equipment: Embedded as part of larger modular control architectures.

Product Advantages

• High Channel Density: Provides 16 analog outputs in a compact footprint, ideal for space-constrained cabinets.

• Precision Control: 16-bit resolution ensures consistent and accurate signal output for sensitive applications.

• Hot Swappable: Enables replacement or upgrades without shutting down the system, minimizing operational disruptions.

• Industrial Hardened Design: Operates reliably in extreme temperatures, humidity, and vibration environments.

• Built-in Diagnostics: Each channel includes real-time health monitoring for faults such as open circuits or shorts.

• Backplane Integration: Seamless communication with HC900 CPUs for high-speed signal processing and configuration.

• Flexible Deployment: Suitable for both standalone and distributed systems with various control topologies.

• Certified Safety: Designed for use in hazardous environments with multiple global approvals.

Frequently Asked Questions (FAQ)

1. Q: How many analog outputs does the 900B16-0001 support?

   A: The module provides 16 independent analog output channels, each capable of 4-20 mA signal output.

2. Q: Can this module be used in hazardous area installations?

   A: Yes, it is FM-approved for Class I Division 2 hazardous areas and meets global certification standards.

3. Q: What level of resolution does the analog output offer?

   A: Each output channel provides 16-bit resolution for high-precision control.

4. Q: Is the module suitable for redundant control systems?

   A: While the module itself isn’t redundant, it integrates into HC900 systems that support redundancy at the controller and power supply level.

5. Q: Can I configure the outputs via software?

   A: Yes, configuration is done through Honeywell’s Control Designer software.

6. Q: Does the module support both voltage and current outputs?

   A: No, this specific model (900B16-0001) supports only current outputs (4-20 mA).

7. Q: Are the channels isolated from each other?

   A: Yes, all channels are isolated from each other and from the system backplane for safety and signal integrity.

8. Q: Can the module be removed while the system is running?

   A: Yes, the 900B16-0001 is hot-swappable, allowing safe module replacement during operation.

9. Q: What tools are required for installation?

   A: Standard DIN rail installation tools; software setup requires Control Designer.

10. Q: What are the dimensions and weight of this module?

    A: The module measures 137 x 35.6 mm and weighs 0.4 kg.
