The GE D25-0158-000003 Automation Controller is a versatile and efficient solution designed to streamline substation operations. This multifunctional device combines the capabilities of a communication and data concentrator, automation controller, metering device, and fault recorder into a single, compact unit.

Key Features

Multifunctional Design:

This feature reduces complexity and costs by consolidating multiple functions into one device.

Flexible and Modular:

The device suits both large-scale projects and smaller installations, offering adaptability to various substation needs.

Data Retrieval and Diagnostics:

It retrieves data from legacy and third-party devices. This capability provides valuable insights into system performance and facilitates diagnostics on primary equipment.

Power Quality Monitoring:

The controller accurately measures and records key power quality parameters. It tracks total harmonic distortion (THD), harmonic spectrum, RMS trending, voltage sags, swells, and interruptions.

Fault Recording:

It captures critical fault data for analysis and troubleshooting, with up to 16 MB of local storage.

Comprehensive I/O Capabilities:

The device offers a wide range of digital and analog input and output options. This variety accommodates various field device connections.

Advanced Communication:

The controller supports over 120 SCADA protocols, including IEC 61850. This support ensures seamless integration with existing systems.

Local HMI Options:

You can choose between a Data Display Panel or a Graphical Display Panel (GDP) for local control and monitoring.

Automation Tools:

It includes LogicLinx®, a powerful IEC 61850 compliant tool for creating custom automation applications.

Applications

The GE D25-0158-000003 Automation Controller is ideal for:

• Substation automation and control
• Power quality monitoring and analysis
• Data acquisition and management
• Remote monitoring and control
