Honeywell TC-OAV061 Experion LS Analog Output Module

As a component in Honeywell’s distributed control system (DCS), the TC-OAV061 plays a vital role in critical applications such as batch control, continuous process control, and precision analog regulation in industries like oil & gas, power generation, petrochemicals, and pharmaceuticals.

Product Specifications

Product Applications

The Honeywell TC-OAV061 is utilized in a variety of industrial control environments where precise analog signal output is crucial. Applications include:

• Distributed Control Systems (DCS) in process automation

• Industrial actuators control (valves, dampers)

• Control loops in chemical or pharmaceutical manufacturing

• Boiler and burner control in power plants

• Analog signal transmission to field devices in oil refineries

• Flow, pressure, and level control systems

Product Advantages

• High Precision: With 12-bit resolution, TC-OAV061 ensures accurate analog output for precise control.

• Robust Isolation: Offers superior channel-to-channel and system-level electrical isolation, minimizing interference.

• Reliable Diagnostics: Built-in loop supervision and fault reporting enable early fault detection, improving uptime.

• Redundant Communication: Compatible with redundant I/O links, ensuring fail-safe communication with the controller.

• Compact Design: Space-saving form factor suitable for high-density I/O panels.

• Easy Maintenance: Modular hot-swappable design simplifies replacements and reduces downtime.

FAQs

Q1: What is the function of the TC-OAV061 module?

A1: It is used to generate analog current signals (4–20 mA) from a control system to field devices like actuators or control valves.

Q2: How many output channels does TC-OAV061 support?

A2: The module supports 8 independent analog output channels.

Q3: Can this module be used in hazardous environments?

A3: Yes, it meets industrial certifications like UL and CE for safe use in industrial settings.

Q4: Is TC-OAV061 hot-swappable?

A4: Yes, it supports hot-swapping for ease of maintenance without shutting down the system.

Q5: Does the module support output signal diagnostics?

A5: Yes, it has built-in loop supervision and fault detection for each channel.

Q6: What is the power supply requirement?

A6: It typically requires a 24 VDC supply for operation.

Q7: What type of isolation does it offer?

A7: It provides both channel-to-channel and channel-to-system isolation.

Q8: Can TC-OAV061 be used with Experion PKS?

A8: Yes, it is fully compatible with Honeywell’s Experion PKS and C300 platforms.

Q9: What is the recommended load resistance?

A9: The output load should be within 0 to 750 Ohms.

Q10: What mounting options are available?

A10: It can be DIN-rail or panel mounted for flexibility in installation.
