The Honeywell CC-PDOD51 is a high-performance Series C Digital Output Module. It supports 32 SINK-type output channels and ensures fast, reliable signal switching. It provides galvanic isolation and supports redundant configurations, making it ideal for demanding process control systems.

Technical Specifications

• Model Number: CC-PDOD51
• Product Type: Series C Digital Output Module
• Output Channels: 32
• Output Type: SINK (Open Drain)
• Load Voltage: 15–30 VDC (Maximum)
• Load Current: 0.1 A per channel (Max)
• On-State Voltage: 0 V DC (at 0.1 A max load)
• Off-State Voltage: 24 V (Typical)
• Off-State Leak Current: 100 µA (Max)
• Turn-On/Turn-Off Time: 10 ms (Max)
• Galvanic Isolation: 1000 VAC RMS system-to-field isolation
• Redundancy: Optional redundancy available
• Coating: Conformal coated for protection
• Power Supply: User-supplied field power required
