General Electric IC660TBA026 Terminal Assembly

The GE IC660TBA026 Terminal Assembly is a field wiring component designed for use with GE’s Genius I/O discrete and analog blocks. As part of the GE Fanuc IC660 series, this terminal assembly serves as the physical interface between the I/O block and field wiring, ensuring safe, efficient, and organized electrical connections in industrial control systems.

Designed for demanding industrial environments, the IC660TBA026 features robust construction, durable screw terminals, and compatibility with a range of block types. It plays a critical role in distributed control systems by reducing wiring complexity and ensuring long-term operational stability. Its simple, modular installation makes it a preferred choice for system integrators and OEMs alike.

Technical Specifications

Product Applications

The IC660TBA026 is commonly used in a wide variety of industrial sectors, especially in distributed I/O systems where space, reliability, and clarity in wiring are paramount.

• Industrial Automation Lines

  For connecting sensors, push-buttons, switches, and indicators to Genius I/O blocks.

• Power Generation Plants

  Interfaces between control panels and field instrumentation for turbines, breakers, and transformers.

• Water/Wastewater Management

  Manages remote I/O blocks for pump control, tank levels, and flow monitoring.

• Pharmaceutical and Food Processing

  Ensures clean wiring layout and modular system design in regulated environments.

• Material Handling Systems

  Used in conveyors, robotics, and sorting systems for signal routing and machine control.

• Oil & Gas Industry

  Field connections in remote installations, offering rugged, vibration-resistant terminal points.

Product Advantages

• Reliable Field Wiring Interface

  24 terminals provide dependable and tight connections using screw compression design.

• Broad Compatibility

  Works seamlessly with various GE Genius I/O blocks (discrete and analog).

• Quick Installation

  Terminal layout simplifies wiring and reduces commissioning time.

• Industrial Grade Durability

  Operates across wide temperature and humidity ranges, ensuring field reliability.

• Maintenance Friendly

  Easy identification and removal without disrupting existing wiring.

• Modular & Scalable

  Easily expandable for systems requiring multiple terminal assemblies.

• Safe & Certified

  Meets international safety certifications (UL, CE, CSA).

• Compact Footprint

  Designed to conserve control panel space without compromising access.

• Cost-Effective

  Minimizes downtime and wiring errors, reducing maintenance costs over time.

• Secure Mounting Options

  Can be mounted both on panels and DIN rails, supporting various installation environments.
