ABB PP D114 B1022 3BHE020570R1022 AC800 Control Module

The ABB PP D114 B1022 3BHE020570R1022 AC800 Control Module is a high-performance processor unit designed for use within ABB’s AC800 series distributed control systems (DCS). It functions as the core computational and coordination unit for industrial process automation, providing robust control performance, fast communication, and reliable integration with a wide range of ABB I/O and communication modules.

This control module incorporates a high-speed 32-bit industrial processor that ensures deterministic real-time control for continuous and batch processes. It is equipped with redundant communication ports, advanced diagnostic capabilities, and an extended temperature range, allowing it to operate in harsh industrial environments such as power plants, chemical refineries, steel manufacturing facilities, and offshore oil platforms.

Built to meet the highest reliability standards, the PP D114 B1022 module offers fault-tolerant operation, high electromagnetic immunity, and superior noise resistance. Its modular design enables seamless system expansion and easy integration with ABB’s Control Builder software suite for configuration, programming, and system monitoring.

Technical Specifications

Product Applications

The PP D114 B1022 3BHE020570R1022 module is designed to provide flexible and precise control across a wide range of process industries. It is used as a core control unit in distributed control architectures where reliability, performance, and integration flexibility are critical.

• Power Generation: Controls turbine operations, synchronization systems, and boiler automation.

• Oil & Gas Processing: Manages refining operations, compressor stations, and offshore platform control.

• Chemical & Petrochemical Industries: Coordinates reactors, distillation columns, and process safety systems.

• Metallurgical & Mining Applications: Provides real-time control for furnaces, rolling mills, and cooling systems.

• Pulp & Paper Industry: Handles process loops for pulp refining, paper drying, and machine automation.

• Marine & Offshore Automation: Controls propulsion, navigation, and energy management systems.

This module’s deterministic control behavior, multi-protocol communication, and high fault tolerance make it ideal for mission-critical automation processes that require continuous 24/7 operation.

Product Advantages

• High-Speed Processing Performance

  The powerful 32-bit processor ensures rapid execution of control algorithms, suitable for both continuous and batch process control.

• Comprehensive Communication Support

  Offers multiple communication options, including Ethernet, PROFIBUS, and Modbus, allowing seamless integration into complex control networks.

• Rugged and Durable Design

  Built with industrial-grade materials and conformal coating for protection against vibration, humidity, and dust.

• Scalable Architecture

  The modular AC800 platform allows for flexible system expansion with additional I/O and communication modules.

• Advanced Diagnostic Tools

  Provides system self-checks, fault logging, and LED status indicators for efficient troubleshooting.

• Redundancy and Reliability

  Supports redundant operation for high-availability systems, minimizing downtime during maintenance or faults.

• Easy Integration and Configuration

  Fully compatible with ABB’s Control Builder M software, simplifying configuration, logic programming, and online modifications.

• Low Power Consumption

  Optimized design ensures efficient operation and reduced heat generation.

FAQ

1. What is the main function of the ABB PP D114 B1022 module?

   It acts as the main processor and control unit within the AC800 control system, managing control logic, data communication, and coordination among connected I/O modules.

2. Which communication interfaces are available on this module?

   It supports Ethernet, PROFIBUS-DP, Modbus RTU/TCP, and CAN bus interfaces for seamless system connectivity.

3. Does this module support redundancy operation?

   Yes, the PP D114 B1022 can operate in a redundant configuration to improve reliability and system uptime.

4. How is programming performed for this module?

   Programming and configuration are done through ABB’s Control Builder M software, which supports IEC 61131-3 standard languages.

5. Can it communicate with third-party devices?

   Yes, thanks to its open communication protocols such as Modbus and TCP/IP, it can communicate with third-party PLCs and devices.

6. What diagnostic features are available?

   It includes self-diagnostic functions, error reporting, and LED status indicators for real-time operational feedback.

7. How does the module handle I/O expansion?

   It supports expansion through ABB I/O modules connected via the system bus, allowing scalable system architecture.

8. Is the module suitable for harsh environments?

   Yes, it features high vibration tolerance, wide temperature range, and protection against electrical disturbances.

9. How can firmware be updated?

   Firmware can be safely updated using ABB’s system tools through the Ethernet service interface.

10. What power supply range does it support?

    It operates within an 18–30 VDC range, providing flexibility for industrial power systems.
