The GE Fanuc IC693PWR321L is a power supply module designed for the Series 90-30 PLC systems. It ensures stable power to the CPU, I/O modules, and other components, ensuring reliable performance in industrial automation applications. The module is installed in the leftmost slot of the PLC baseplate and supports both AC and DC inputs.

Technical Specifications

• Model: IC693PWR321L
• Manufacturer: GE Fanuc
• Type: Power Supply Module
• Nominal Rated Voltage: 120/240 VAC or 125 VDC
• Input Voltage Range: 85 to 264 VAC or 100 to 300 VDC
• Input Power: 90 VA (VAC) or 50 W (VDC)
• Load Capacity: 30 Watts

Output Voltages

• +5 VDC: 5.0 VDC to 5.2 VDC (Nominal 5 VDC)
• +24 VDC Relay: 24 to 28 VDC
• +24 VDC Isolated: 2.5 VDC to 28 VDC

Protective Limits

• Overvoltage: 6.4 to 7 V for +5 VDC output
• Overcurrent: 4 A maximum for +5 VDC output
• Inrush Current: 4A peak, 250 milliseconds maximum
• Holdup Time: Minimum 20 milliseconds

Location and Communication

• Installation: Leftmost slot on the PLC baseplate
• Communication: RS-485 Serial Port
