Bently Nevada 3500/02 129133-02 System Architecture and Rack Configuration

Bently Nevada 3500/02 129133-02 system is an industrial solution for monitoring and protecting critical rotating machinery. Its architecture and rack configurations support its operation. The rack interface module (RIM) manages the communication and data between rack modules and is critical to each rack.

The power module provides power to all modules and allows for redundant power supply setups. The vibration monitoring module tracks equipment vibration levels, working with a variety of sensors such as accelerometers. The temperature monitoring module checks equipment temperature using thermocouples and RTD sensors. The speed monitoring module supports magneto-electric or photoelectric sensors to monitor equipment speed. Overall, it provides a comprehensive set of capabilities for machinery health monitoring.

Fuctions & Features

• Rack Interface Module (RIM): 3500/02 129133-02 is responsible for the communication and data management of the modules in the rack. Each rack must be equipped with a RIM module.

• Power Module: 3500/02 129133-02 provides power to all modules in the rack and supports redundant power configuration.

• Vibration Monitoring Module: 3500/02 129133-02 is used to monitor the vibration level of the equipment and supports a variety of sensors (such as accelerometers, speed sensors).

• Temperature Monitoring Module: 3500/02 129133-02 is used to monitor the temperature of the equipment and supports thermocouples and RTD sensors.

• Speed ​​Monitoring Module: 3500/02 129133-02 is used to monitor the speed of the equipment and supports magnetoelectric or photoelectric sensors.

• Process variable monitoring module: 3500/02 129133-02 is used to monitor process variables such as pressure and flow.
