ABB TU814V1 3BSE013233R1 Compact Module Termination Unit

ABB TU814V1 3BSE013233R1 Compact Module Terminal Unit 2x8, signal terminals for crimp-on snap-in connectors, supports up to 16 I/O channels and 2 process voltage connections, with removable (pluggable) connectors.

Although the TU814V1 is a mechanical configuration, it does not affect the functions of the MTU and I/O modules. The two mechanical keys have six positions each, allowing a total of 36 different configurations.

Keywords:

Uses three-row crimp-on quick connectors

Supports 16 independent I/O channel connections

Provides 2 process voltage connection interfaces

Fuctions & Features

• The TU814V1 features up to 16 I/O channels and two process voltage connections, each rated up to 50V and 2A.

• The TU814V1 can be configured in up to 36 different ways using two mechanical keys to accommodate different I/O modules.

• The TU814V1 unit features three rows of crimp-on snap-on connectors for field signals and process power.

• The TU814V1 has two isolation groups of 8 channels each with voltage monitoring

Specification
