ABB GRBTU-01 3BSE013175R1 Module Terminal Unit
Manufacturer:ABB
Product Number:GRBTU-01 3BSE013175R1
Product Type:Module Terminal Unit
Origin:Sweden
Dimensions:120 × 90 × 65 mm
Weight:0.18 kg
Views:42
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
Product Description
The ABB GRBTU-01, part number 3BSE013175R1, is a high-quality Module Terminal Unit (MTU) designed for use within ABB’s 800xA and Symphony Plus automation platforms. This component plays a critical role in connecting field wiring to I/O modules safely and efficiently. As a base unit for mounting I/O modules, it provides mechanical support, electrical interfacing, and structured terminal connectivity between process instrumentation and the automation system.
The GRBTU-01 ensures secure signal transmission and simplifies system integration by offering standardized terminal layouts, pre-defined labeling, and robust contact interfaces. It is optimized for compatibility with ABB’s redundant I/O systems, ensuring high availability and reliability in mission-critical industrial environments.
Product Specifications
| Parameter | Details |
|---|---|
| Product Name | ABB GRBTU-01 Module Terminal Unit |
| Part Number | 3BSE013175R1 |
| Product Type | Module Terminal Unit (MTU) |
| System Compatibility | ABB 800xA, Symphony Plus |
| I/O Type | Redundant Analog/Digital I/O Modules |
| Connection Interface | Screw-type terminal connections |
| Terminal Capacity | Up to 2.5 mm² wire cross-section |
| Mounting Type | DIN Rail Mountable (EN 50022 standard) |
| Number of Terminals | 32-channel terminal base |
| Electrical Isolation | Galvanic isolation between system and field signals |
| Operating Voltage | Up to 30V DC (as per I/O module specs) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Flame Class (Housing) | UL94 V-0 |
| Certifications | CE, RoHS, UL, cUL, IEC/EN 61131-2 |
| Dimensions (H × W × D) | 120 × 90 × 65 mm |
| Weight | 0.18 kg |
| Enclosure Protection | IP20 (when installed in cabinet) |
Applications
The ABB GRBTU-01 is purpose-built for complex industrial automation systems, particularly where redundancy and high reliability are critical. Common application sectors include:
Power Generation Plants
Used in turbine control systems and balance-of-plant operations.
Oil & Gas Facilities
Supports wellhead, compressor, and process station I/O integration with redundancy.
Chemical & Petrochemical Plants
Facilitates safe analog/digital signal interfacing for instrumentation in hazardous areas.
Water and Wastewater Treatment
Provides I/O expansion capability for flow, pressure, and pump station automation.
Pulp & Paper Industry
Interfaces with I/O modules for process control in digesters, paper machines, and stock prep.
Mining and Metals Processing
Enhances monitoring and control of conveyor systems, crushers, and smelters.
Key Advantages
Redundancy-Ready Design
Supports dual-channel I/O modules and fault-tolerant architectures for critical operations.
Simplified Field Wiring
Clearly labeled terminals and structured layout improve installation speed and minimize errors.
DIN-Rail Mountable
Quick installation in standardized control cabinets with secure mechanical stability.
Galvanic Isolation
Protects the controller and I/O circuits from electrical disturbances in the field wiring.
Maintenance-Friendly
Terminal marking, wiring space, and access points are optimized for fast troubleshooting.
Durable Construction
Designed to withstand harsh industrial environments, with robust materials and protective housing.
Wide System Compatibility
Seamlessly integrates with ABB’s 800xA and Symphony Plus control environments.
Scalable Architecture
Supports modular expansion of I/O capabilities across distributed systems.
Frequently Asked Questions (FAQ)
Q: What is the primary function of the GRBTU-01?
A: It serves as a terminal unit to connect field wiring to I/O modules in ABB control systems.
Q: Which automation systems is the GRBTU-01 compatible with?
A: It is compatible with ABB’s 800xA and Symphony Plus systems.
Q: Is this terminal unit designed for redundant I/O?
A: Yes, it supports redundant analog or digital I/O module configurations.
Q: What is the maximum wire size it supports?
A: It supports up to 2.5 mm² wire cross-sections.
Q: Can this unit be mounted horizontally and vertically?
A: It is typically DIN rail mounted horizontally but can adapt to cabinet space as needed.
Q: Does the GRBTU-01 offer electrical isolation?
A: Yes, it provides galvanic isolation between field and system-side circuits.
Q: What is the enclosure protection rating?
A: It offers IP20 protection when installed inside an enclosure.
Q: Is special software required for configuring this terminal unit?
A: No, the terminal unit itself does not require configuration—it’s a passive hardware interface.
Q: What temperature range can it operate in?
A: It operates between -20°C and +70°C.
Q: How is it labeled for maintenance or wiring purposes?
A: Terminal positions are clearly labeled to simplify wiring and service.
