General Electric IS200DSPXH1D IS200DSPXH1DBC IS200DSPXH1DBD Digital Signal Processor Control Board

GE IS200DSPXH1D (IS200DSPXH1DBC and IS200DSPXH1DBD) is a digital signal processor control board developed by GE Mark VI. It is the primary controller for the bridging, motor regulation and gate control operations of the innovative series drives, while also managing the generator excitation control functions of the EX2100 excitation control, providing logic, processing and interface functions. The board consists of a digital signal processor), standard memory components and application specific integrated circuits that perform custom logic functions.

Fuctions & Features

• Load Pulse Synchronization: The GE IS200DSPXH1D internal loop load pulse signal records the bridge, motor or generator voltage and current, VCO, speed counter and discrete input I/O values, and can also synchronize ISBus channels, software and bridge gate output.

• Memory Support: The GE IS200DSPXH1D supports multiple memory types, FLASH is used to store DSP boot images, code execution, configurable item storage and system history.

• System Control Function: The GE IS200DSPXH1D serves as the main controller for the bridge, motor regulation and gate control operations of the Innovation Series drives, manages the generator excitation control functions of the EX2100 excitation control, and provides logic, processing and interface functions for the system.

Specification
