General Electric IS200SRLYH2AAA Simplex Relay Output Terminal Board
Item Number: IS200SRLYH2AAA
Brand: GE
Lead Time: In stock
Description: Simplex Relay Output Terminal Board
Payment: T/T
Product Description
GE IS200SRLYH2AAA is the Simplex Relay Output Terminal Board in the GE Mark VI series. This terminal board provides 12 sets of Form C (conversion type) relay outputs, a total of 48 client terminals, fixed to the control cabinet by a metal bracket, equipped with a plastic insulating pad, the option board can be directly inserted and fixed by the connector.
Note:The IS200SRLYH2AAA itself has no jumper, and the configuration depends on the option board.
Function & Features
- Output type: 12 Form C (SPDT, single-pole double-throw) relays, each relay provides 1 pair of isolated contacts.
- Configuration mode: IS200SRLYH2AAA can configure the relay power supply through the jumper of the option board, supporting dry contact (passive) or energized output mode (jumper removed=dry contact).
- Terminal board structure: IS200SRLYH2AAA belongs to S-type terminal board, supports double-layer stacking of terminal boards, and the terminal layout and I/O module are unified with other S-type terminal board installation methods.
Specifications
|
Parameter |
Details |
|
Model |
IS200SRLYH2A IS200SRLYH2AAA |
|
Series |
GE Mark VI |
|
Relay Type |
12×Form C (SPDT) |
|
Terminal Quantity |
48 customer terminals (12 relays × 4 terminals/relay) |
|
Option Board Support |
-WROBH1: Relay power jumper configuration -WROFH1: Fuse protection and voltage detection |
|
I/O Module Compatibility |
PDOA/YDOA modules |
Loading comments...
