Woodward 5464-355 NetCon Module
Item Number:5464-355
Brand:Woodward
Price:$1
Lead Time: In stock
Description:NetCon Module
Payment: T/T
Product Description
Woodward 5464-355 NetCon Module was developed by Woodward and is a communication interface module designed for EM/GS/LQ digital actuator drives. The 5464-355 module is equipped with three RS-485 ports. Each port allows communication with one drive every 5 milliseconds, and the address switch of the drive must match the drive number in the GAP application.
Function & Features
- The 5464-355 is equipped with 3 independent RS-485 ports, each port is dedicated to connecting to EM/GS/LQ digital actuator drivers, and supports independent rate groups per port.
- Key parameters are updated every 5 milliseconds (one driver per port).
- The 5464-355 automatically detects communication failures and abnormal drivers are disabled.
- Drive address dip switches need to match the numbers in the GAP application.
Specifications
|
Details |
|
|
Voltage Inputs |
3 true RMS voltage inputs |
|
Current Inputs |
3 true RMS current inputs |
|
Accuracy - Voltage, Frequency, Current |
Class 0.5 accuracy |
|
Accuracy - Real and Reactive Power or Energy |
Class 1 accuracy |
|
Trip/Control Setpoints |
Configurable |
|
Delay Timers for Alarms |
Configurable (0.02 to 300.00 s) |
|
4 configurable relays (change - over) 1 "Ready for operation" relay |
|
|
Relay Logic |
Switchable |
|
Configuration |
Configurable via CAN bus / RS - 485 / Service Port (USB/RS - 232) |
|
24 Vdc power supply |
