GE Fanuc IC693MDL748 Positive/Negative Logic Output Module
Manufacturer: GE Fanuc
Product Number: IC693MDL748
Category: Positive/Negative Logic Output Module (Series 90-30 PLC)
Number of Outputs: 16
Output Type: 24 VDC, source/sink configurable
Output Current: 0.5 A per channel
System Compatibility: Series 90-30 PLC family
Product Description
The GE Fanuc IC693MDL748 is a discrete output module designed for the Series 90-30 PLC family. It provides 16 output points capable of sourcing or sinking current (positive or negative logic) at 24 VDC, each rated up to 0.5 A. This flexibility allows the module to interface with a variety of DC load types such as solenoids, relays, and indicators. With its robust construction, fast switching capability, and built-in output protection, the IC693MDL748 is ideal for general-purpose industrial control applications.
Key Features
-
16 Discrete Outputs–High-density output in a single-slot module
-
Positive/Negative Logic Support–Configurable for sourcing or sinking applications
-
24 VDC Operation–Compatible with standard DC control voltages
-
Output Protection–Includes overcurrent and short-circuit protection
-
LED Status Indicators–Visual feedback for each output channel
-
System Compatibility–Designed for seamless integration with GE Fanuc Series 90-30 PLCs
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 118 x 33 x 89 mm |
| Weight | 0.3 kg |
Electrical Characteristics
| Item | Specification |
|---|---|
| Number of Outputs | 16 (single group) |
| Output Type | Discrete DC outputs (positive/negative logic) |
| Operating Voltage | 24 VDC nominal (range: 5–30 VDC) |
| Output Current Rating | 0.5 A per point (max 4 A per module) |
| Output Delay | ON: ≤ 0.2 ms, OFF: ≤ 0.3 ms |
| Protection | Overcurrent, short-circuit, and thermal overload |
| Isolation | 1500 V RMS (field to logic) |
Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration Resistance | IEC 60068-compliant |
System Compatibility
| Item | Specification |
|---|---|
| Compatible Systems | GE Fanuc Series 90-30 PLCs |
| Mounting Type | Installed in standard I/O slot in Series 90-30 base |
Industry Applications
-
Automated Machinery–Drives solenoids, contactors, and signal lights
-
Material Handling–Controls conveyors, actuators, and sorting equipment
-
Water Treatment–Activates valves and pumps in process sequences
-
Energy and Utilities–Manages auxiliary equipment in substations or plants
-
Manufacturing Systems–Suitable for general discrete output tasks across production lines
The GE Fanuc IC693MDL748 Output Module combines flexible logic output capability with high-performance switching and protection, making it a dependable solution for a broad range of discrete automation control tasks within Series 90-30 PLC environments.
