ABB FI810F 3BDH000030R1 FI 810F Fieldbus Module

The ABB FI810F 3BDH000030R1 is a CAN fieldbus module designed for the ABB AC800F controller. It features a triple-channel CAN interface for connecting various CAN devices such as sensors, actuators, and controllers. Built for harsh industrial environments, it adheres to the CAN 2.0B standard.

Technical Specifications

• Bus type: CAN 2.0B
• Number of channels: 3
• Baud rate: Up to 1 Mbit/s
• Transmission distance: Up to 1 km (depending on cable type and baud rate)
• Electrical isolation: 2 kV
• Operating temperature: -40 to +70 °C
• Dimensions: 125 x 155 x 28 mm
• Weight: 0.145 kg

Features

• Three independent CAN channels for versatile connectivity.
• High-speed data transmission ensures quick communication.
• Electrical isolation protects against ground faults.
• Wide operating temperature range accommodates harsh environments.
• Compact design allows for space-saving installation.

Applications

• Industrial automation systems
• Process control environments
• Building automation projects
• Transportation systems
• Medical devices

Benefits

• Increased communication speed and efficiency.
• Improved system reliability with robust design.
• Reduced installation and maintenance costs due to compact size.
• Scalable solution fits a wide range of applications.
