The Honeywell CC-PDIL01 51405040-175 is a high-quality Digital Input Module specifically designed to interface with Honeywell’s industrial control systems. The module provides reliable digital signal input from field devices such as sensors, switches, and other binary devices in process control systems. With robust construction, high reliability, and ease of integration, this module is ideal for a wide range of applications in industries such as manufacturing, oil & gas, and power generation.

The CC-PDIL01 is optimized for use in harsh industrial environments, ensuring stable and precise operation even under challenging conditions. The module’s wide input voltage range and noise immunity make it suitable for various process control applications where accurate digital signal processing is essential.

Key Features

• Wide Input Voltage Range: Accepts input voltages from 10 V DC to 30 V DC, ensuring compatibility with a broad range of field devices.

• High Noise Immunity: Designed to work in industrial environments with high electrical noise, ensuring stable signal processing.

• Compact Design: Space-saving design that can easily be integrated into control panels and distributed I/O systems.

• Status LEDs: Provides clear visual feedback with LED indicators for each channel to show the status of input signals.

• Extended Temperature Range: Suitable for use in industrial environments with operating temperatures from -20°C to +60°C.

• Modular Design: Can be easily integrated with Honeywell’s distributed control systems, offering flexibility and scalability.

• Direct Integration with Control Systems: Seamlessly integrates with Honeywell’s Experion and Safety Manager control systems for streamlined operation.

• High Reliability: Designed to meet stringent industry standards, ensuring long-lasting and reliable performance in critical systems.

• Easy Installation: Simplifies setup and reduces maintenance time with a user-friendly interface and modular connections.

Technical Specifications

Industry Applications

• Manufacturing – Suitable for integration in automated manufacturing plants to monitor switches, sensors, and control signals.

• Oil & Gas – Used in hazardous locations for safety systems and process control systems.

• Power Generation – Monitors field devices in power plants, ensuring continuous and accurate data collection.

• Chemical Processing – Ensures reliable signal input from safety devices and pressure/switch sensors in chemical plants.

• Water & Wastewater Treatment – Suitable for monitoring digital inputs from water treatment plants and wastewater facilities.

• Automotive – Used in automotive manufacturing for tracking assembly line sensors and machine controls.

Product Advantages

• Wide Compatibility – Works with a broad range of field devices and control systems.

• Rugged and Reliable – Built to handle industrial conditions, including temperature fluctuations and electrical noise.

• Flexible Integration – Easily integrates with Honeywell Experion and other Honeywell distributed control systems.

• Enhanced Safety – Meets IEC 61508 and IEC 61131-2 standards for safety and reliability in critical control applications.

• Space-Efficient Design – Compact form factor that minimizes the need for extensive panel space.

• Real-Time Feedback – LED status indicators allow operators to quickly verify the signal status of each input channel.

Frequently Asked Questions (FAQ)

1. What types of field devices are compatible with the CC-PDIL01 module?

   The module supports dry contact, switch closure, and 24 V DC source inputs, making it compatible with a variety of field devices such as sensors and switches.

2. How many channels does the CC-PDIL01 module have?

   The CC-PDIL01 module provides 16 digital input channels, organized in 4 groups of 4 inputs.

3. What is the input voltage range of this module?

   It accepts input voltages from 10 V DC to 30 V DC, making it versatile for different field devices.

4. What is the operating temperature range?

   The module can operate within a temperature range of -20°C to +60°C, suitable for harsh industrial environments.

5. Does the module provide any status indicators?

   Yes, the module includes LED indicators for each input channel, providing clear feedback on the status of the signals.

6. Is the module compatible with Honeywell control systems?

   Yes, it integrates seamlessly with Honeywell Experion and Safety Manager control systems.

7. What type of isolation is provided for the inputs?

   The module features galvanic isolation between input channels and the control system, ensuring protection from electrical faults.

8. How is the module installed?

   The module can be mounted on DIN rails or directly on a panel, offering flexibility in installation.

9. What certifications does the module have?

   The CC-PDIL01 is certified to CE, UL, RoHS, IEC 61131-2, and IEC 61508 standards.

10. Is the CC-PDIL01 suitable for use in hazardous locations?

    While the module is robust and reliable, for hazardous locations, it’s essential to verify specific certifications related to explosion-proof environments.
