The GE IC660ELD100 is a Genius I/O Electronic Input Block, designed and manufactured by General Electric for use in industrial automation and control systems. It is part of the GE Fanuc Series 90-30/70 Genius I/O family, which enables distributed I/O configurations in high-performance environments. The IC660ELD100 is primarily used to interface with a variety of discrete sensors and switches, collecting digital input signals and transmitting them to a central controller via the Genius I/O network. This allows for efficient and scalable automation solutions across diverse industries.

This input block supports 16 discrete inputs and is well-regarded for its rugged construction, ease of installation, and flexible communication capabilities. With its ability to operate in harsh environments and deliver high-speed data exchange, the IC660ELD100 has become a dependable choice in complex manufacturing setups, particularly in automotive, chemical, and process industries.

Key Features of GE IC660ELD100

• Supports 16 discrete input channels

• Compatible with sourcing and sinking input devices

• Built-in diagnostics for enhanced reliability

• Hot insertion and removal supported

• DIN rail or panel mounting options

• Wide input voltage range for flexibility

• Compatible with Genius Bus for distributed I/O systems

• Rugged enclosure suitable for industrial environments

Technical Specifications

Applications of GE IC660ELD100

The GE IC660ELD100 is widely adopted in applications where digital signal acquisition is critical to the automation process. It is used in:

• Factory Automation: Capturing signals from sensors and switches on assembly lines.

• Process Control Systems: Interfacing with field instruments in chemical, oil & gas, and water treatment plants.

• Material Handling: Monitoring conveyor belts, sorters, and other equipment.

• Packaging Systems: Enabling logic control based on sensor status.

• Automotive Manufacturing: Synchronizing discrete operations on robotic work cells.

• Utility and Energy Management Systems: Integrating with control logic for real-time input monitoring.

Advantages of GE IC660ELD100

• Scalable Architecture: Easy integration into both small and large Genius I/O networks.

• Reduced Wiring Costs: Genius Bus significantly reduces the need for point-to-point wiring.

• Reliable Operation: Built for high-reliability performance in industrial environments.

• Fast Data Processing: Real-time signal handling enables quick response in time-sensitive applications.

• Diagnostic Capability: Helps in quick fault isolation and reduces system downtime.

• Versatile Mounting: Fits easily into existing panels or DIN systems.

• Broad Compatibility: Works seamlessly with a wide range of sensors and controllers in GE Fanuc systems.

Frequently Asked Questions (FAQ)

Q1: What kind of inputs does the IC660ELD100 accept?

A1: It accepts 16 discrete digital inputs, compatible with both sourcing and sinking devices operating at 0–32 VDC.

Q2: Can the IC660ELD100 be installed on a DIN rail?

A2: Yes, it supports both DIN rail and panel mounting, providing flexibility for installation.

Q3: Is this module hot-swappable?

A3: Yes, the IC660ELD100 can be inserted or removed from the system while powered, minimizing downtime.

Q4: What network does this block communicate over?

A4: It communicates via the Genius I/O bus, a proprietary GE high-speed serial network.

Q5: How is the health of the block or inputs monitored?

A5: The module includes built-in diagnostics for each input channel and overall module status.

Q6: Can the IC660ELD100 operate in outdoor environments?

A6: It is intended for indoor use; however, with appropriate enclosures (e.g., IP-rated cabinets), it can be adapted for harsher settings.

Q7: What controllers are compatible with this I/O block?

A7: It is compatible with GE Fanuc Series 90-30, 90-70, and other Genius Bus-capable controllers.

Q8: What certifications does it have?

A8: It carries UL, CE, and CSA certifications, ensuring it meets industrial safety standards.

Q9: Is any software required to configure this module?

A9: Yes, configuration tools compatible with GE Genius Bus systems are required for network setup.

Q10: What is the expected lifespan of the IC660ELD100?

A10: When used under specified operating conditions, the module typically has a lifespan exceeding 10 years.
