ABB GJR2363200R0001 87TS01E Coupler Module

The ABB GJR2363200R0001 87TS01E is a three-phase, dry-type transformer designed for a variety of applications, including power distribution, industrial automation, and renewable energy systems. Featuring a hermetically sealed transformer with a cast resin core and coil assembly, it offers excellent protection against moisture, dust, and other contaminants. Additionally, the transformer is equipped with a low-loss core material and high-efficiency windings to minimize energy losses and enhance overall efficiency.

Technical Specifications

• Rated power: 200 kVA
• Primary voltage: 4160 V
• Secondary voltage: 480 V
• Frequency: 60 Hz
• Number of phases: 3
• Connection: Y-Y
• Cooling method: Dry-type
• Core material: Grain-oriented silicon steel
• Winding material: Copper
• Insulation class: H
• Degree of protection: IP20
• Weight: 2,200 lbs
• Dimensions: 55″ x 36″ x 36″

Features

• Hermetically sealed design: Provides protection against moisture, dust, and other contaminants.
• Low-loss core material: Improves efficiency.
• High-efficiency windings: Reduces energy losses.
• Dry-type construction: Ensures quiet operation and low maintenance.
• Versatile applications: Suitable for power distribution, industrial automation, and renewable energy systems.

Applications

• Power distribution
• Industrial automation
• Renewable energy systems
• Machine tools
• Data centers
• Medical equipment

Benefits

• Improved efficiency: Reduced energy losses.
• Extended transformer life
• Reduced maintenance costs
• Improved reliability
• Quiet operation
