The Woodward 8440-1750 Turbine Control Module is a compact, high-performance controller designed to manage and protect turbine and generator systems in power generation, industrial, and marine environments. Part of Woodward’s renowned easYgen series, this module integrates essential functions such as synchronization, load sharing, engine protection, and system monitoring into a single, rugged unit.

With advanced communication capabilities, flexible I/O configuration, and robust environmental protection, the 8440-1750 provides reliable control for both standalone and grid-connected generator and turbine systems. Its intuitive interface and powerful software make installation, configuration, and operation straightforward for engineers and operators alike.

Key Features and Advantages

• Integrated Turbine and Generator Control: Combines synchronization, load sharing, protection, and monitoring functions in one module.

• Wide Voltage and Frequency Range: Supports sensing of generator voltages from 50 to 650,000 VAC and frequencies between 40 to 70 Hz.

• Flexible Input/Output Configuration: Offers configurable digital and analog I/O to adapt to various system requirements.

• Advanced Event Recording: Records up to 300 events with real-time clock and battery backup for traceability and diagnostics.

• Rugged Industrial Design: Compact, durable housing with IP54 protection, suitable for harsh environments.

• Global Certification: UL/cUL listed and marine-certified by GL (Germanischer Lloyd) and LR (Lloyd’s Register).

• Wide Power Supply Range: Operates reliably on DC voltages from 6.5 to 40 VDC.

• User-Friendly Interface: Equipped with graphical display and intuitive menu navigation for easy setup and operation.

• Compact and Space-Saving: Optimized dimensions make it suitable for control panels with limited space.

• Seamless Integration: Compatible with Woodward control systems and third-party automation platforms.

Technical Specifications

Applications

• Power generation turbine and generator control

• Marine generator sets and propulsion system management

• Industrial backup power and prime power control systems

• Synchronization and load sharing in multi-generator installations

• Grid-tied generator operation with utility interface functions

• Remote and microgrid power system management

• Process industry standby and emergency power solutions
