With its precision-engineered architecture and fault-tolerant design, the 5A26141G06 ensures seamless connectivity and consistent data exchange between field devices and control logic. The module is engineered to meet the rigorous demands of 24/7 plant operations.

Technical Specifications

Product Advantages

• Seamless DCS Integration: Optimized for use with Ovation systems, ensuring native compatibility and zero protocol translation loss.

• High Signal Integrity: Provides optically isolated channels for noise immunity and reliable signal recognition.

• Hot Swapping Support: Enables the module to be replaced during operation without system downtime.

• Enhanced Diagnostics: Features onboard diagnostics for rapid fault identification, increasing system uptime.

• Compact Design: Small footprint allows high-density installation, reducing cabinet space requirements.

• Industrial-Grade Build: Resistant to thermal fluctuations, humidity, and electrical interference.

• Maintenance-Friendly: Simple module identification, extraction handle, and LED status indicators.

• Field-Proven: Trusted in long-term deployments in utilities and critical infrastructure sites.

Typical Applications

• Power Generation Plants (thermal, hydro, nuclear)

• Water and Wastewater Treatment Facilities

• Oil & Gas Process Control Systems

• Chemical and Petrochemical Plants

• Pulp and Paper Automation

• Substation Monitoring & Control

• Distributed Infrastructure Monitoring

• Boiler and Turbine Control Systems

Installation Notes

• Slot Assignment: Must be installed in an I/O base carrier compatible with the Ovation I/O backplane.

• Wiring: Ensure field wiring conforms to voltage rating and channel configuration.

• Environment: Maintain installation within specified environmental parameters (temperature, humidity).

• Commissioning: Use Ovation engineering tools to configure and test the module post-installation.

• Grounding: Proper chassis and field ground must be ensured for safety and noise reduction.

• Spare Parts: Recommend maintaining minimum 2 spares for critical applications.

Frequently Asked Questions (FAQ)

Q1: What type of signals can the 5A26141G06 handle?

A1: This module handles digital (discrete) signals, commonly used for binary ON/OFF status detection from field equipment.

Q2: Can I remove this module without shutting down the control system?

A2: Yes. The module is hot-swappable, allowing removal and replacement while the system remains online.

Q3: How many channels are available on this model?

A3: The 5A26141G06 offers 16 configurable channels, each independently isolated.

Q4: Is this module suitable for safety applications?

A4: While robust and reliable, it should be used in safety systems only if the application permits non-redundant architectures. Always follow plant-specific safety protocols.

Q5: How is this module configured?

A5: Configuration is done through the Ovation engineering workstation, which allows for channel assignment, diagnostics, and logic testing.

Q6: What is the recommended operating temperature?

A6: The recommended operating temperature is 0°C to 60°C, ensuring optimal performance.

Q7: Does the module support channel diagnostics?

A7: Yes, built-in diagnostics are available for fault detection and status reporting per channel.

Q8: What certifications does the 5A26141G06 hold?

A8: The module is CE and RoHS compliant, and adheres to IEC industrial standards.

Q9: How is the module secured in the rack?

A9: It uses a latching mechanism with an extraction handle, locking it into the backplane slot.

Q10: What is the weight of the module?

A10: The module weighs approximately 0.55 kilograms, facilitating easy handling during maintenance.
