The 5701 Series Control System is a sophisticated microprocessor-based system designed to display readings and statuses from connected gas detectors. This system offers robust alarm handling capabilities and comprehensive maintenance features.

In a rack system, multiple single-channel control cards are installed, each paired with an associated field/relay card responsible for sensor input and optional relay output connections. Each channel control card independently handles basic alarm operations and operations.

For more complex alarm handling, communication takes place between a designated number of control cards via the rack’s backplane. An engineering card is also installed in each rack, serving to manage rack backplane communications, control card interrogation, and facilitating maintenance tasks. Additionally, optional modules on the engineering card can provide extra system outputs.

System power supplies, auxiliary power supplies, and battery backup systems are typically connected to the rack via a DC Input Card. However, for installations demanding high integrity, power supplies can be directly linked to each individual control card.
