The Ovation 1C31122G01 Digital Output Module is a vital component within the Ovation Distributed Control System (DCS), designed to deliver reliable and precise digital output signals to control field devices such as actuators, solenoids, and relays. This module offers 16 discrete output channels, each capable of switching digital signals that represent control commands from the Ovation system to the field equipment.

Engineered with robust construction and industry-standard interfaces, the module is optimized for high-speed switching and long-term durability. It plays a crucial role in the automation of power plants, industrial processes, and critical infrastructure, where dependable digital output control is essential for maintaining operational safety and efficiency.

Product Specifications

Applications

• Power Generation Control: Driving critical field devices such as turbine valves and breakers with reliable digital commands.

• Process Automation: Controlling discrete actuators, solenoids, and motor starters in refining, chemical, and manufacturing industries.

• Water Treatment Plants: Managing pumps, valves, and alarms in automated water and wastewater treatment systems.

• Oil & Gas Facilities: Used for remote control of safety and process shutdown devices.

• Building Automation: Managing lighting systems, HVAC controls, and security systems with digital output signals.

• Infrastructure Control Systems: Application in power distribution, transportation signaling, and other industrial control processes requiring dependable discrete outputs.

Advantages

• High Channel Density: Offers 16 output channels in a compact form factor, maximizing panel space efficiency.

• Fast and Accurate Switching: Ensures prompt response to control system commands with minimal latency.

• Galvanic Isolation: Protects output channels and control system from electrical interference and noise.

• Robust and Reliable: Designed for long-term operation in harsh industrial environments.

• Simple Integration: Seamless plug-in module compatible with the Ovation backplane and DCS architecture.

• Low Power Consumption: Optimized for efficient operation with minimal heat generation.

• Enhanced Safety: Supports fault detection and diagnostic features to ensure system integrity.

• Maintenance-Friendly: Easy to replace or upgrade with minimal system disruption.

Frequently Asked Questions (FAQ)

1. What is the purpose of the Ovation 1C31122G01 module?

   It serves as a digital output interface, sending discrete control signals to field devices.

2. How many channels does this module support?

   It supports 16 discrete digital output channels.

3. What type of output signals does it provide?

   The module outputs digital discrete signals, typically relay or transistor driven.

4. What is the maximum output current per channel?

   Each channel can handle up to 0.5 A.

5. Is there electrical isolation between channels?

   Yes, it features galvanic isolation between channels to prevent interference.

6. What are the physical dimensions and weight of the module?

   The module measures 132 x 108 x 35 mm and weighs 0.34 kg.

7. Can this module operate in extreme temperatures?

   It operates safely between -20°C and +70°C.

8. What is the power supply requirement?

   The module requires a nominal 24 V DC power supply.

9. How does this module connect to the Ovation system?

   It connects via the backplane bus interface of the Ovation control system rack.

10. Is the module easy to replace or upgrade?

    Yes, it is designed for plug-and-play installation, facilitating easy maintenance.
