Emerson KJ3002X1-BF1 12P1732X042 RTD Card Datasheet Product Overview

The Emerson KJ3002X1-BF1 12P1732X042 RTD Card is a vital component of the AMS 6500 Machinery Health Monitor system. It is designed to accurately measure and monitor temperature in various industrial applications.

The card utilizes Resistance Temperature Detectors (RTDs) to convert temperature variations into electrical signals, providing reliable temperature data for machinery health monitoring and protection.

Key Features

• Dual-channel temperature measurement The KJ3002X1-BF1 12P1732X042 card can simultaneously measure temperatures from two independent RTD sensors, enabling comprehensive monitoring of critical equipment components.
• High accuracy The card offers high accuracy temperature measurement, with a resolution of 0.1°C, ensuring precise temperature readings for reliable analysis and decision-making.
• Wide temperature range The card supports a wide temperature range of -200°C to 800°C (-328°F to 1472°F), catering to a diverse range of industrial applications.
• Galvanic isolation The card features galvanic isolation between the input and output circuits, protecting it from electrical noise and interference, ensuring signal integrity and measurement reliability.
• RS-485 communication The KJ3002X1-BF1 12P1732X042 card utilizes RS-485 communication protocol, enabling seamless integration into existing control and monitoring networks.

Specifications

• Input type RTD (Pt100, Pt1000, Cu100, JPt100)
• Temperature range -200°C to 800°C (-328°F to 1472°F)
• Accuracy ±0.1°C
• Resolution 0.1°C
• Communication protocol RS-485
• Power supply 24 VDC or 12 VDC
• Operating temperature -40°C to 85°C (-40°F to 185°F)
• Protection rating IP67
• Dimensions 120 mm x 60 mm x 21 mm (4.72 in x 2.36 in x 0.83 in)
• Weight 0.2 kg (0.44 lb)

Applications

The Emerson KJ3002X1-BF1 12P1732X042 RTD Card finds extensive applications in various industrial settings, including

• Power generation Monitoring temperatures in turbines, generators, and other critical components to ensure efficient operation and prevent overheating.
• Oil and gas Measuring temperatures in pipelines, pumps, compressors, and other equipment to maintain optimal process conditions and prevent safety hazards.
• Manufacturing Tracking temperatures in furnaces, motors, conveyors, and other machinery to optimize production processes and prevent equipment damage.
• Chemical processing Monitoring temperatures in reactors, vessels, and pipelines to ensure product quality and safety during chemical reactions.
• Pulp and paper Measuring temperatures in digesters, dryers, and other equipment to control paper manufacturing processes and maintain product quality.

Additional Features

• The Emerson KJ3002X1-BF1 12P1732X042 RTD Card is CE certified.
• The card is backed by Emerson’s global support network, providing prompt assistance and expertise.
• It is compatible with the AMS 6500 Machinery Health Monitor system, enabling comprehensive machinery health monitoring and protection.
