AB 1769-L35CR Detailed Introduction

Allen‑Bradley 1769-L35CR is an industrial automation component produced by Rockwell Automation(formerly Allen-Bradley).The following is a detailed introduction to the product.

Basic information

Brand:Allen-Bradley/Rockwell Automation

Model:1769-L35CR

Type:CompactLogix controller module

Technical specifications

Power supply voltage:600V

Power:20A

Frequency:industrial frequency

User memory:1.5MB

Supported programming languages:relay ladder diagram,function block diagram,structured text,sequential function block

Communication interface:It comes with 1 RS-232 communication port and 1 ControlNet control network communication port,supporting multiple communication protocols,such as Modbus,CANopen,etc.,so as to integrate with other automation systems.

Module expansion capability:Up to 30 1769 series modules can be expanded

Supported CompactFlash cards:Models are 1784-CF64(64M memory)and 1784-CF128(128M memory)

Features

High performance:The CompactLogix platform has the characteristics of compact structure and excellent performance.1769-L35CR,as its controller module,can meet the needs of high-performance control.

Scalability:Through module expansion,1769-L35CR can be combined with other 1769 series modules to form a more complex control system.

Network integration:Support EtherNet/IP(Ethernet),ControlNet(control network)or DeviceNet(device network)network,which is convenient for network control with other devices.

Multitasking:1769-L35CR supports 8 tasks,only 1 of which runs as a continuous task,and supports consumer tag data and event instruction triggers.

Built-in protection function:It has safety functions such as overload protection and short circuit protection to protect the system from damage.

Application Scenarios

General Control:1769-L35CR is suitable for a variety of general control applications,such as speed control of pumps and fans,variable speed operation of conveyor belts,smooth lifting of cranes and elevators,precise positioning control of machine tools,etc.

Device-level Control:As a CompactLogix controller module,1769-L35CR is particularly suitable for small equipment,equipment-level control applications,with or without simple motion control.
