Technical Parameters of ABB CP661-WEB Control Panel Display (1SAP561200R0001)

The ABB CP661-WEB Control Panel Display (1SAP561200R0001) is a high-performance Human-Machine Interface (HMI) designed for industrial automation applications, offering advanced visualization, connectivity, and control capabilities. Below are its key technical specifications:

Display Specifications

• Display Size: 12.1-inch TFT LCD
• Resolution: 800 x 600 pixels (SVGA)
• Color Depth: 16.7 million colors
• Brightness: 300 cd/m² (typical)
• Viewing Angle: 80° (H) / 80° (V)
• Backlight: Long-life LED (50,000 hours MTBF)

Processor & Memory

• CPU: High-performance ARM Cortex-A8 or equivalent
• RAM: 256 MB DDR3
• Flash Memory: 256 MB (expandable via SD card)
• Real-Time Clock: Built-in battery-backed RTC

Connectivity & Communication

• Ethernet: 1 x 10/100 Mbps RJ45 (support for Modbus TCP, OPC UA, and other protocols)
• USB: 2 x USB 2.0 Host ports (for peripheral devices, data logging, or firmware updates)
• Serial Ports: 1 x RS-232/RS-485 (configurable, support for Modbus RTU, ASCII, etc.)
• Web Server: Integrated HTTP/HTTPS server for remote monitoring and control
• VPN Support: Optional VPN tunneling for secure remote access

Operating System & Software

• Firmware: ABB Panel Builder 600 (or compatible) for configuration
• Supported Protocols: Modbus TCP/RTU, OPC UA, Profibus (via optional module), Siemens S7, etc.
• Web Functionality: HTML5-based web interface for remote access
• Security: User authentication (multi-level access control), SSL/TLS encryption

Environmental & Mechanical Specifications

• Operating Temperature: 0°C to +50°C (32°F to 122°F)
• Storage Temperature: -20°C to +60°C (-4°F to 140°F)
• Humidity: 5% to 95% RH (non-condensing)
• Vibration Resistance: 10–57 Hz, 0.075 mm double amplitude (IEC 60068-2-6)
• Shock Resistance: 15 g, 11 ms (IEC 60068-2-27)
• IP Rating: IP65 front panel (NEMA 4/4X compliant)
• Mounting: Panel/flush mounting (cutout dimensions: 310 x 235 mm)

Power Supply

• Input Voltage: 24 VDC ±20% (19.2–28.8 VDC)
• Power Consumption: Max. 30 W (typical 15 W)
• Reverse Polarity Protection: Built-in

Certifications & Compliance

• CE, UL, cUL, GL, DNV, ABS (Marine), ATEX (optional for hazardous areas)
• EMC Compliance: EN 61000-6-2, EN 61000-6-4
• RoHS Compliant

Additional Features

• Multi-Touch Support: Resistive or projected capacitive (PCAP) touchscreen (optional)
• Alarm Management: Configurable alarms with event logging
• Data Logging: Built-in historian for trend analysis
• Remote Desktop: VNC/RDP support for full remote control
• Multilingual Support: Unicode-based UI for global deployments

Applications

The ABB CP661-WEB is ideal for:

• Industrial automation (process control, manufacturing, energy)
• Marine & offshore applications (due to IP65/NEMA 4X rating)
• Building automation (HVAC, lighting control)
• Water/wastewater treatment plants
• Oil & gas (with optional ATEX certification)

Conclusion

The ABB CP661-WEB Control Panel Display (1SAP561200R0001) combines robust industrial design with advanced web-based connectivity, making it a reliable choice for modern automation systems requiring remote monitoring and control.

For detailed datasheets or custom configurations, refer to ABB’s official documentation or contact an authorized ABB distributor.
