The GE IC694MDL646C is a part of the GE Fanuc 90-30 series of programmable logic controllers (PLC). It is designed to offer high-level automation control for various industrial applications, providing reliable and effective control over machinery, processes, and systems. This module specifically functions as a 16-point isolated relay output and provides various advantages in terms of flexibility, durability, and ease of integration into control systems. The IC694MDL646C ensures smooth communication between PLC and the actuators in your setup, offering both high-speed control and stable performance in harsh environments.

It is built to meet the high demands of factory automation, process control, and monitoring systems, making it essential for industries like automotive manufacturing, food processing, oil and gas, and more.

Product Specifications

Product Applications

The GE IC694MDL646C is primarily used in industrial control systems for monitoring and controlling outputs that are connected to devices such as actuators, motors, and other mechanical systems. This relay output module is ideal for applications requiring electrical isolation, ensuring the PLC system is protected from electrical surges or noise.

Its applications include:

1. Factory Automation – controlling machinery and production lines.

2. Process Control – managing and automating systems in chemical plants, water treatment, and other process industries.

3. Building Automation – controlling HVAC systems, lighting, and other electrical systems.

4. Energy Management – facilitating the control of power distribution systems.

5. Automotive Manufacturing – monitoring production lines, robotic arms, and material handling systems.

Advantages of the GE IC694MDL646C

• Isolated Outputs: Provides electrical isolation between the PLC and the output devices, protecting the system from high-voltage spikes or electrical interference.

• High Reliability: Designed for long-term operation in demanding environments, with a wide operating temperature range and excellent resistance to vibration and electrical noise.

• Ease of Integration: The compact size and standardized mounting options make the IC694MDL646C easy to integrate into a variety of existing automation setups.

• Flexible I/O Configuration: With 16 relay output points, it offers significant flexibility in controlling multiple devices simultaneously.

• Cost-Effective: Provides high performance at a competitive price point, reducing the overall cost of the automation system.

• Robust Design: Built to last with high-quality components that ensure minimal downtime and maintenance needs.

FAQs

1. What is the voltage rating for the GE IC694MDL646C?

   • The module operates at a nominal output voltage of 24V DC.

2. How many points are available on this module?

   • The IC694MDL646C features 16 output points.

3. What is the maximum current per output point?

   • The maximum current rating is 2A per point.

4. What is the operating temperature range of the IC694MDL646C?

   • The module operates between 0°C to 60°C (32°F to 140°F).

5. What type of module is the IC694MDL646C?

   • This is an isolated relay output module used in PLC systems.

6. Can this module be used in process control systems?

   • Yes, it is ideal for applications in process control where isolated relay outputs are necessary.

7. What are the mounting requirements for the GE IC694MDL646C?

   • The module is designed to be mounted on a DIN rail.

8. What is the weight of the IC694MDL646C?

   • The module weighs 0.258 kg.

9. Can this module be used in high-vibration environments?

   • Yes, it is designed to withstand vibration and harsh industrial conditions.

10. What is the humidity tolerance of this module?

    • The module can operate in environments with a relative humidity of 5% to 95% (non-condensing).
