The Bently Nevada 3500/22M-01-01-00 138607-01 Transient Data Interface Module is a high-performance device designed to integrate seamlessly with the Bently Nevada 3500 series machinery protection and condition monitoring systems. It serves as the interface between transient data acquisition equipment and monitoring systems, enabling the capture and processing of critical dynamic signals. These signals are vital for assessing machinery behavior under real-time operational conditions, providing a comprehensive view of machine health and performance.

This module is particularly beneficial in industries where rotating machinery is critical, such as power generation, oil and gas, chemical processing, and manufacturing. It helps detect faults early, such as imbalance, misalignment, and bearing wear, by continuously monitoring transient signals like vibration and displacement. By doing so, it supports predictive maintenance, reducing downtime and preventing costly equipment failure.

Built with reliability in mind, the 3500/22M-01-01-00 138607-01 module ensures that your equipment operates efficiently. Its robust design, coupled with ease of integration into existing systems, makes it an ideal solution for industries aiming to enhance operational efficiency and extend the lifespan of critical machinery.

Key Features

• High-Precision Transient Data Acquisition: The module captures high-fidelity transient data from machinery, which is essential for detecting anomalies and understanding operational behavior.

• Real-Time Monitoring: Continuous monitoring allows for the immediate detection of any faults in machinery, enabling real-time intervention before major breakdowns occur.

• Seamless Integration: It integrates perfectly with the 3500 series, ensuring a fully functional system for rotating machinery protection.

• Enhanced Digital Signal Processing: Utilizes advanced processing capabilities for high-accuracy data interpretation and fault detection.

• Compact Design: Despite its powerful capabilities, it features a 241.3 x 24.4 x 241.8 mm form factor, which allows easy installation in tight spaces.

• Durable Construction: Designed to withstand industrial environments, including extreme temperatures, vibrations, and exposure to chemicals.

• Cost-Effective: Helps prevent costly downtime and repairs by detecting early signs of failure, enabling proactive maintenance.

Product Parameters

Product Applications

The 3500/22M-01-01-00 138607-01 Transient Data Interface Module is used in various industries and applications where transient data acquisition and monitoring of machinery health are critical. Key applications include:

• Power Generation: In power plants, it is used to monitor turbines, generators, and other essential equipment, providing real-time data for performance assessment and fault detection.

• Oil & Gas: In the oil and gas industry, it helps monitor pumps, compressors, and other machinery, ensuring optimal operation and early identification of issues like imbalance, misalignment, or wear.

• Chemical Processing: The module captures transient data from pumps, mixers, and other equipment, ensuring smooth operation and preventing unplanned shutdowns due to undetected faults.

• Manufacturing: In manufacturing settings, it is used to monitor presses, conveyors, motors, and other high-precision machinery, reducing the risk of production delays caused by equipment failure.

• Compressor and Pump Monitoring: The module plays an essential role in monitoring equipment such as compressors and pumps, detecting issues like cavitation or vibration imbalance before they escalate into more significant problems.

• Industrial Automation: It is crucial in industrial automation systems, providing real-time data that helps optimize machinery performance and ensure safety.

Advantages of the Product

1. High Accuracy: Offers precise transient data acquisition, enabling detailed analysis of machinery behavior and early detection of faults.

2. Real-Time Fault Detection: Constant monitoring allows for the detection of anomalies in machinery immediately, reducing the risk of unexpected failures and costly downtime.

3. Ease of Integration: The module seamlessly integrates into the Bently Nevada 3500 series, making it part of a comprehensive machinery protection system.

4. Compact and Space-Saving: Despite its robust features, it has a compact form factor, allowing for installation in tight industrial spaces.

5. Durable and Reliable: The module is built to withstand harsh industrial environments, including extreme temperatures, vibration, and chemical exposure.

6. Improved Maintenance Strategy: Helps implement predictive maintenance by providing real-time data on machinery conditions, enabling timely maintenance actions.

7. Cost Savings: By identifying faults early and preventing unplanned downtime, the module helps reduce maintenance costs and prevent significant equipment damage.

8. Energy-Efficient: With a power consumption of 12 W, the module provides high performance while consuming minimal energy.

9. Flexible Application: Suitable for use in various industries such as power generation, oil and gas, and manufacturing.

10. Easy Installation: Its 19″ rack mount design makes it easy to install in existing monitoring systems, ensuring compatibility and ease of use.

Frequently Asked Questions (FAQ)

1. What is the primary function of the Bently Nevada 3500/22M-01-01-00 138607-01 module?

   • The module collects and processes transient data from rotating machinery, enabling real-time monitoring and early detection of faults.

2. How does the 3500/22M-01-01-00 138607-01 module support predictive maintenance?

   • It captures transient data that helps detect potential faults early, allowing for predictive maintenance and reducing unexpected downtime.

3. What industries can benefit from the Bently Nevada 3500/22M-01-01-00 138607-01 module?

   • It is ideal for industries such as power generation, oil and gas, chemical processing, manufacturing, and industrial automation.

4. What is the size of the 3500/22M-01-01-00 138607-01 module?

   • The module has dimensions of 241.3 x 24.4 x 241.8 mm, making it compact and easy to install in 19-inch racks.

5. What is the power consumption of this module?

   • The module has a typical power consumption of 12 W, ensuring energy efficiency during operation.

6. Can the module be installed in a standard rack?

   • Yes, the module can be installed in a 19″ rack mount, making it compatible with standard industrial monitoring setups.

7. What types of data does the 3500/22M-01-01-00 module capture?

   • The module captures transient data from machinery, including vibration, displacement, and other operational parameters.

8. What temperature range can the module operate in?

   • The module can operate in temperatures ranging from -40°C to 85°C, making it suitable for various industrial environments.

9. What is the weight of the 3500/22M-01-01-00 138607-01 module?

   • The module weighs 0.91 kg, which is lightweight for its size and capabilities.

10. How does the module communicate with other Bently Nevada systems?

    • The module uses Ethernet or serial communication protocols to transmit data to other 3500 series components.
