GE Fanuc IC693MDL740 12/24 Volt DC Logic 0.5 Amp Output Module

The GE Fanuc IC693MDL740 is a positive logic output module designed for use in the Series 90-30 PLC system. It provides 16 digital output points, organized into two groups of 8 channels. Each output channel can handle up to 0.5 Amps of current, making it ideal for controlling various electrical loads such as relays, solenoids, and motor starters. The module operates with a voltage range of 12 to 24 VDC (+20%, –15%) and utilizes sourcing logic to deliver current to connected devices. The IC693MDL740 is equipped with front panel LED indicators that show the status of each channel and the module’s operation.

Technical Specifications

• Module Type: Positive Logic Output Module
• Series: GE Fanuc Series 90-30
• Part Number: IC693MDL740
• Output Channels: 16 points (2 groups of 8)
• Voltage Range: 12 to 24 VDC (+20%, –15%)
• Output Current: 0.5 Amps per channel
• Maximum Output Current per Common: 2 Amps
• Inrush Current: 4.78 Amps for 10 ms
• Output Voltage Drop: 1 VDC maximum
• Response Time:
  • ON: 2 ms maximum
  • OFF: 2 ms maximum
• Power Consumption: 110 mA (all outputs on)
• Operating Temperature: 0 to 60°C
• Storage Temperature: -40 to 85°C
• Relative Humidity: 5% to 95%
• Isolation:
  • 1500 V between field and logic sides
  • 500 V between groups
• LED Indicators: For individual channel and module status
• Mounting: Screw terminals
• Compatibility: GE Fanuc 90-30 PLCs
• Weight: 0.71 lbs
