GE Fanuc IC693CPU311D Baseplate with Embedded CPU

The GE Fanuc IC693CPU311D is a Series 90-30 PLC central processing unit (CPU) designed for industrial automation systems. It features a modular design, making it adaptable for various applications, from manufacturing to process control. The IC693CPU311D integrates a CPU into a 5-slot baseplate, allowing users to expand their system with additional I/O or communication modules. With a 16-bit processor and a 10 MHz clock speed, this unit is suited for applications requiring solid performance in controlling machinery, assembly lines, or process management.

Technical Specifications

• System Architecture:
  • 16-bit system: Provides efficient data processing and control capabilities.
• Processor Specifications:
  • Processor type: 80188
  • Clock speed: 10 MHz, enabling fast execution of control logic.
• Memory:
  • User Program Memory: 6K Bytes for storing the control program.
  • Registry Memory: 1K Byte, used for variable storage during program execution.
• I/O Capacity:
  • Total I/O points: 160 (Digital and Analog signals).
  • Analog I/O: 64 input, 32 output channels for flexible integration.
• Slot Configuration:
  • I/O slots: 5 slots available for expansion modules.
  • Power supply slot: 1 dedicated slot for power input.
• Operating Parameters:
  • Typical scan rate: 18 ms per 1K logic, ensuring quick response times.
  • Boolean execution speed: 18 ms per 1K logic.
  • Current load: 410 milliamps, indicating typical power consumption.
• Environmental:
  • Operating temperature range: 32°F to 140°F (0°C to 60°C), making it suitable for a variety of industrial environments.
• Ports and Connectivity:
  • Serial ports: 1 port for communication with other devices in the system.
• Physical Dimensions:
  • Weight: 1.20 lbs
