The ABB Bailey IMAMI01 is a specialized Auto/Manual Interface Module designed for use within ABB’s INFI 90 Distributed Control System (DCS). It acts as a bridge between automatic control functions and manual operator intervention, ensuring that control strategies can be safely and seamlessly overridden or maintained during manual operations or maintenance conditions.

The IMAMI01 plays a crucial role in process industries where operator-driven control actions must override system automation without compromising safety, accuracy, or process integrity. Through robust design and reliable communication with multifunction processors and output modules, the IMAMI01 ensures a dependable switch between manual and automatic modes, contributing significantly to system flexibility and uptime.

Technical Specifications

Product Applications

The IMAMI01 is vital in a range of industrial process settings, particularly where human intervention and automation must coexist:

• Chemical & Petrochemical Plants: Enables operators to safely override automatic valve positions during abnormal events.

• Oil & Gas Facilities: Allows for manual pump operation during commissioning or shutdowns.

• Power Generation Units: Facilitates turbine or boiler manual control during testing and startup.

• Pharmaceutical Manufacturing: Used during batch corrections or manual sampling routines.

• Water Treatment Plants: Operators can manually adjust flow and dosage during calibration.

• Pulp & Paper Mills: Supports manual speed control of conveyors or rollers for maintenance purposes.

Product Advantages

• Safe Manual Override: Ensures uninterrupted process control when switching from auto to manual operation.

• High System Integration: Fully compatible with INFI 90 architecture and multifunction processors.

• Intuitive Operation: LED indicators provide clear visual status of control mode.

• Fail-Safe Design: Retains the last valid command to the output devices upon communication failure.

• Compact Form Factor: Fits in existing ABB rack systems with minimal installation effort.

• Reliable Communication: Uses the INFI 90 I/O bus for robust and fast data exchange.

• Operator Flexibility: Allows on-site personnel to make real-time adjustments as needed.

• Extended Operational Life: Industrial-grade construction ensures long-term durability.
