The ABB PM5650-2ETH 1SAP141000R0278 is a robust CPU module designed for the ABB AC500 series of programmable logic controllers (PLCs). This controller delivers high processing power and dual Ethernet ports for flexible networking, making it ideal for complex and scalable industrial automation tasks.

Built to handle demanding applications, the PM5650-2ETH provides fast execution, extensive memory, and wide protocol support, ensuring reliable control in manufacturing, process industries, infrastructure, and building automation. Its modular architecture supports seamless expansion, enabling integration with ABB’s comprehensive range of I/O and communication modules.

Key Features

• High-speed CPU for advanced control and fast processing

• Dual Ethernet ports supporting 10/100 Mbps for flexible network topology

• Large program and data memory for complex applications

• Supports IEC 61131-3 programming languages (ST, LD, FBD, SFC, IL)

• Expandable with ABB AC500 modular I/O and communication modules

• Integrated diagnostics and fault detection for increased system reliability

• Wide operating temperature range suitable for industrial environments

• Compatible with ABB Automation Builder for efficient programming and commissioning

Technical Specifications

Product Applications

The PM5650-2ETH PLC is suitable for a wide range of automation tasks that require reliable control and extensive communication capabilities, including:

• Manufacturing Automation: Control of machinery, assembly lines, and robotics

• Process Automation: Chemical plants, water treatment, and energy systems

• Building Automation: HVAC, lighting, and facility management systems

• Infrastructure: Transport systems, tunnels, and utilities

• OEM Solutions: Embedded automation in industrial equipment

• Renewable Energy: Monitoring and control of wind, solar, and energy storage systems

Product Advantages

• Dual Ethernet Ports: Enables flexible network configurations and segmentation

• High Processing Capability: Fast execution suitable for time-critical applications

• Modular Expansion: Easily expandable with ABB’s broad range of I/O and communication modules

• Wide Protocol Support: Compatible with common industrial protocols for integration

• Robust Design: Industrial-grade reliability with wide operating temperature range

• User-Friendly Programming: Full support for IEC 61131-3 languages via ABB Automation Builder

• Diagnostic Features: Integrated fault detection and diagnostics improve uptime

• Global Compliance: Certified for international standards and regulations

Frequently Asked Questions (FAQ)

1. What is the main use of the PM5650-2ETH?

It serves as a high-performance CPU for industrial automation systems requiring dual Ethernet connectivity.

2. How many Ethernet ports does it have?

It features two integrated Ethernet ports supporting 10/100 Mbps.

3. What programming languages are supported?

Supports all IEC 61131-3 standard languages including Structured Text, Ladder Diagram, and others.

4. Can this PLC be expanded?

Yes, it supports expansion with ABB AC500 modular I/O and communication modules.

5. What communication protocols does it support?

Includes Modbus TCP, OPC, Ethernet/IP, TCP/IP, UDP, and custom protocols.

6. What is the operating temperature range?

From -25°C to +60°C, suitable for most industrial environments.

7. Is it suitable for building automation?

Yes, it can be used for HVAC, lighting, and other building control applications.

8. Does it include real-time clock functionality?

Yes, it has an integrated real-time clock with battery backup.

9. How is programming performed?

Using ABB Automation Builder software supporting IEC 61131-3 languages.

10. Is the PM5650-2ETH certified for global use?

Yes, it complies with CE, UL, cUL, RoHS, and IEC standards.
