The ABB PFXA 401 is a robust control unit designed for various industrial applications. It integrates seamlessly with ABB’s load cells and edge sensors. Here are its key features and technical specifications:

Key Features

• Analog Inputs: The unit includes 2 analog inputs for connecting load cells or edge sensors.
• Angle Compensation: This feature compensates for the angle of the load cell to ensure precise measurements.
• Compatibility: It supports ABB’s QGPR 102/104 load cells (up to 2 MN) and PFBL 101/141 load cells. It can handle up to 2 x 400 kN for 2 edge sensors PMSG 123/125.
• Power Supply: The control unit operates on a lithium battery, complemented by a protective fuse.
• Connections: It offers various connection terminals for mains, sync, and other inputs/outputs.

Technical Specifications

• Model: PFXA 401
• Catalog Description: PFXA 401 Control Unit
• Analog Inputs: 2
• Angle Compensation: For load cell QGPR 102/104, max. 2 MN
• Compatibility: For load cell PFBL 101/141. Supports up to 2 x 400 kN for 2 edge sensors PMSG 123/125
• Battery: Lithium
• Fuse: 2A 250V (Part Number: 3BSC790006R1)
• Mains Connection: 4-pole disconnectable terminals (Part Number: 2664197-4)
• Sync Connection: 3-pole disconnectable terminals (Part Number: 2664177-3)
• Other Connections:
  • X3, X13, X5, X15: 4-pole disconnectable terminals (Part Number: 2664177-4)
  • X8, X18, X23, X30: 2-pole disconnectable terminals (Part Number: 2664177-2)
  • X6, X16: Analog output, 6-pole disconnectable terminals (Part Number: 2662177-6)
  • X24, X25, X34, X35: Digital signal, 5-pole disconnectable terminals (Part Number: 2664163-5)

Additional Details

• Country of Origin: United States (US), Sweden (SE)
• Customs Tariff Number: 85389091
• Dangerous Goods UN Classification: Class 9, UN3091-PI970
• Gross Volume: 8 dm³
• Gross Weight: 5 kg
• Invoice Description: PFXA 401 Control Unit
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Package Level 1 Gross Weight: 5 kg
• Package Level 1 Units: 1 piece
• Part Type: New
• Product Name: Unclassified
• Product Net Weight: 5 kg
• Product Type: Unclassified
• Quote Only: No
• Selling Unit of Measure: Piece
• Stocked At: Malmö, Sweden
• Technical Information: Designed for precise measurement and control in industrial applications.
