The Woodward 8235-650 Actuator is a high-torque, electrically driven positioning device engineered for precise fuel control in diesel and gas engines. As part of Woodward’s trusted line of industrial actuators, the 8235-650 offers robust performance, fast response, and accurate positioning to ensure optimal engine operation under varying load conditions.

This actuator is designed to interface directly with engine fuel control levers or fuel racks and is typically used in conjunction with electronic speed controls or governors. Its enclosed, rugged housing and industrial-grade construction make it ideal for harsh environmental conditions. The 8235-650 is field-proven for applications demanding stability, reliability, and control responsiveness across diverse engine platforms.

Product Specifications

Product Applications

The Woodward 8235-650 actuator is widely implemented across multiple sectors due to its adaptability, responsiveness, and rugged construction:

• Industrial Diesel Engines: Provides accurate control of fuel injection systems.

• Gas Engines: Used in stationary gensets, compressors, and co-generation units.

• Generator Sets (Gensets): Delivers stable engine speed control in power generation systems.

• Off-Highway Equipment: Implements efficient engine load response in construction or mining vehicles.

• Marine Engines: Ensures precise propulsion engine management in small to mid-size vessels.

• Pump and Compressor Drives: Regulates engine speeds in fluid transfer or air compression applications.

Product Advantages

• High Torque Output: Capable of delivering up to 13 Nm, suitable for medium to heavy-duty fuel control.

• Fast and Precise Movement: Rapid actuation ensures minimal engine lag and efficient load handling.

• Rugged Design: Withstands extreme temperature and vibration in demanding field conditions.

• IP66 Protection: Fully sealed housing prevents ingress of dust and water.

• Flexible Integration: Compatible with most Woodward electronic governors and digital controllers.

• Low Power Consumption: Optimized for extended operation without thermal buildup.

• Easy Installation: Simple mounting options and compact design reduce setup time.

• Maintenance-Free Operation: Sealed construction ensures long-term reliability with minimal upkeep.

• Electromechanical Stability: Provides consistent force and position feedback for closed-loop systems.

• Global Compliance: CE, CSA, and RoHS certifications ensure international usability.
