Foxboro A4H254-8F8T P0973JP Managed Ethernet Switch

The FOXBORO A4H254-8F8T P0973JP is a Layer 2 managed Ethernet switch tailored for industrial and automation networks. It offers a balanced mix of 8 copper and 8 fiber ports, along with uplink and stacking interfaces. This switch supports high-speed, scalable, and secure communication in harsh environments. It is ideal for applications requiring flexible connectivity, robust management, and industrial-grade reliability.

Technical Specifications

Port Configuration

• 8 × 100Base-TX (RJ-45, copper Ethernet)
• 8 × 100Base-FX (MT-RJ, multimode fiber)
• 2 × 10/100/1000 Mbps ISL (RJ-45, stacking/uplink)
• 2 × 1000Base-X SFP ports (Gigabit uplinks using MGBIC modules)

Switching Capabilities

• Full duplex operation on all ports
• Layer 2 Ethernet switching for reliable data forwarding
• High-performance switching fabric with low latency

Management

• Managed switch with full configuration access
• Supports SNMP, RMON, and local console port access
• Advanced diagnostics and remote monitoring tools
• Spanning Tree, VLAN, QoS, and security features supported

Power

• Internal AC Input: Auto-sensing
• Max Power Consumption: 47 Watts
• Max Heat Dissipation: 160 BTUs/hour
• Max Current: 0.5 A @ 110 V AC, 0.47 A @ 220 V AC
• Supports external redundant power supply

Environmental Specifications

• Operating Temperature: 0 to +50°C (32 to 122°F)
• Storage Temperature: -40 to +70°C (-40 to 158°F)
• Relative Humidity: 5 to 95% (non-condensing)
