Honeywell FC-TIDI-1624 Isolated passive Digital Input Module

The Honeywell FC-TIDI-1624 is a high-performance Isolated Passive Digital Input Module, specifically engineered for robust and reliable industrial automation applications. Part of the Honeywell Experion Process Knowledge System (PKS) or PlantScape family, this module is designed to ensure safe and secure collection of digital input signals in critical control systems.

Built with galvanic isolation and high noise immunity, the FC-TIDI-1624 is ideal for interfacing field signals from various sensors and switches to the central controller. It supports passive digital input signals, meaning it detects voltage levels from external sources without supplying power to the field devices. It is often deployed in systems requiring safe signal interfacing in harsh industrial environments such as oil and gas, petrochemical, power generation, and manufacturing plants.

With a robust build, easy installation, and high reliability, the FC-TIDI-1624 ensures that no signal is lost or corrupted, contributing to the integrity and availability of the overall control system.

Product Specifications

Product Applications

• Oil & Gas Facilities: Used for monitoring valve positions, pressure switches, and digital feedback from safety devices.

• Power Plants: Interfaces with breaker positions, turbine control feedback, and digital relays.

• Chemical and Petrochemical Plants: Gathers signals from tank level switches, flow alarms, and emergency stop devices.

• Manufacturing Automation: Integrates digital signals from limit switches, proximity sensors, and emergency systems.

• Water Treatment Plants: Collects field signals from pumps, motor control circuits, and safety interlocks.

Product Advantages

• Robust Isolation: Channel-to-channel and channel-to-system isolation ensures signal integrity and system safety.

• High Channel Density: Offers 16 input channels in a compact module, saving panel space and reducing costs.

• Reliable Performance: Designed for mission-critical applications with high accuracy and low latency.

• Diagnostic Features: Supports health monitoring and fault diagnostics for proactive maintenance.

• Easy Integration: Seamlessly integrates with Honeywell’s Experion PKS systems for optimized plant control.

• Modular Design: Facilitates quick replacement, flexible system expansion, and easy troubleshooting.

• Low Power Usage: Energy-efficient design contributes to overall system efficiency.

• Industrial Grade Design: Built to operate in challenging industrial environments with wide temperature ranges and vibration resistance.

Frequently Asked Questions (FAQ)

1. What type of input signals does the FC-TIDI-1624 support?

   It supports isolated passive digital input signals, typically 24 VDC logic-level inputs.

2. Is the FC-TIDI-1624 suitable for safety-critical applications?

   Yes, it includes isolation and diagnostic features that make it ideal for safety-critical systems.

3. Can the module detect open or short circuit faults?

   Yes, the module features diagnostic capability to detect channel faults including open wires.

4. What systems is it compatible with?

   It is primarily compatible with Honeywell’s Experion PKS and PlantScape systems.

5. Is hot-swapping supported?

   Depending on the system configuration, the module can be replaced with minimal downtime.

6. How is the module mounted?

   It is DIN-rail mountable and designed for compact control cabinets.

7. What certifications does the module carry?

   It is CE marked and compliant with UL, CSA, and RoHS standards.

8. Is this module programmable?

   It is configurable through the Honeywell control system but does not support onboard programming.

9. Can this module be used in harsh environments?

   Yes, it is built to operate in industrial environments with high EMI and temperature variation.

10. What maintenance is required for this module?

    Minimal maintenance is needed; routine diagnostics and system checks are typically sufficient.
