Schneider TM3DI16 Modicon TM3 Discrete Input Module

The Schneider TM3DI16 is a discrete input expansion module designed for use with Modicon M221, M241, and M251 logic controllers. It features 16 digital inputs and provides reliable, compact, and scalable I/O expansion for industrial automation systems.

Technical Specifications

Applications

• Industrial machine control

• Packaging lines

• Conveyor systems

• Process automation

• I/O expansion for compact PLCs

Advantages

• Seamless integration with Modicon M2xx PLCs

• Space-saving design with compact dimensions

• Quick installation with removable terminal blocks

• Cost-effective I/O expansion

• High input density in a small footprint

FAQ

Q1: How many digital inputs does the TM3DI16 module have?

A1: It has 16 discrete digital inputs.

Q2: Is the module compatible with all Modicon controllers?

A2: It is compatible with Modicon M221, M241, and M251 controllers.

Q3: What is the input voltage specification?

A3: The module supports 24 V DC inputs.

Q4: Can this module be mounted on a DIN rail?

A4: Yes, the TM3DI16 is designed for DIN rail mounting.

Q5: What is the isolation between inputs and internal logic?

A5: It provides 500 V AC isolation between input channels and logic.

Q6: Is the terminal block removable?

A6: Yes, it includes removable screw terminal blocks for easy wiring.

Q7: What is the delay time for digital input signal detection?

A7: Typical input delay is 3 ms.

Q8: Can the module handle both sinking and sourcing inputs?

A8: Yes, it supports both sink and source wiring configurations.

Q9: Is this module suitable for harsh environments?

A9: It is rated for IP20 and suitable for industrial panels in clean environments.

Q10: What is the typical use of this module?

A10: It is used to expand the number of input points in an automation system.
