Bently Nevada 3500/20-01-01-00 125744-02 Rack Interface Module

The Bently Nevada 3500/20-01-01-00 125744-02 Rack Interface Module is an essential component within the Bently Nevada 3500 Series monitoring system. This module serves as the critical interface that allows communication between the system’s racks and other components, ensuring reliable data transfer and system integrity. Designed to be robust and user-friendly, it facilitates seamless integration and system expansion while maintaining high operational reliability in demanding industrial environments.

This module is widely adopted in industries where continuous machinery monitoring is paramount, such as power generation, oil and gas, and heavy manufacturing. It supports vibration monitoring, machinery protection, and condition-based maintenance programs by enabling effective data exchange within the 3500 system.

Product Specifications

Product Applications

The 3500/20-01-01-00 Rack Interface Module is primarily used in the following scenarios:

• Turbine and Generator Monitoring: Ensures continuous communication and data integrity within machinery protection systems.

• Oil and Gas Industry: Monitors rotating equipment to prevent unplanned downtime and catastrophic failures.

• Power Plants: Facilitates real-time data transfer for vibration and temperature sensors integrated within control systems.

• Heavy Industry & Manufacturing: Supports condition-based maintenance by enabling rapid, reliable system data access.

• Aerospace and Defense: Used in mission-critical machinery protection applications requiring high reliability.

• Pulp and Paper Industry: Helps maintain operational efficiency by providing precise machinery monitoring.

Product Advantages

The 3500/20-01-01-00 Rack Interface Module offers several notable advantages:

• Robust Communication: Ensures high-integrity data transfer with minimal errors using proprietary protocols.

• Ease of Installation: Designed for straightforward rack mounting and quick system integration.

• Durability: Built to withstand harsh industrial environments with wide temperature and humidity tolerances.

• Diagnostic Feedback: LED indicators allow quick visual status checks for troubleshooting and maintenance.

• Scalability: Supports system expansion without disruption, accommodating growing monitoring needs.

• Compatibility: Fully compatible with the entire Bently Nevada 3500 monitoring system, facilitating seamless interoperability.

• Reduced Downtime: Reliable communication and fault detection improve system availability and reduce maintenance costs.

Frequently Asked Questions (FAQ)

1. What is the primary function of the 3500/20-01-01-00 Rack Interface Module?

   It facilitates communication between the 3500 system rack and monitoring modules, enabling data exchange.

2. Can this module be used in environments with high humidity?

   Yes, it supports operation up to 95% non-condensing humidity.

3. What are the power requirements for this module?

   It operates on a nominal 24 VDC power supply.

4. Is the module compatible with other Bently Nevada 3500 system components?

   Yes, it is fully compatible within the 3500 Series ecosystem.

5. How is the module mounted in the system?

   It is designed for standard rack mounting within the 3500 Series racks.

6. What kind of status indicators does the module provide?

   It includes LEDs for power, communication, and fault status.

7. What temperature range can the module operate within?

   It operates between -40 °C and +85 °C.

8. How do I troubleshoot communication issues?

   Use the status LEDs for initial diagnostics; further troubleshooting can be done through the system’s diagnostic tools.

9. Does the module require any special maintenance?

   Regular visual inspections and ensuring rack connections remain secure is typically sufficient.

10. Are there any certifications for safety and quality?

    Yes, it holds CE and UL certifications.
