GE Fanuc IC693MDL654G Discrete Input Module

The GE Fanuc IC693MDL654G is a discrete input module used with GE Fanuc Series 90-30 programmable logic controllers (PLCs). It provides a reliable interface for monitoring and controlling external input devices such as sensors, switches, and pushbuttons. With its compact design and high-density input configuration, this module is ideal for various industrial automation applications that require efficient input monitoring.

Technical Specifications

• Input Points: 32 discrete input points in a single module.
• Voltage: Operates with 24 VDC positive/negative logic.
• Response Time: Fast 2 ms response time for quick detection of input changes.
• Input Grouping: Four isolated groups of eight inputs, improving noise immunity.
• LED Indicators: Each input point features an LED to indicate its status (on/off).
• Dimensions: 1.3 in (33 mm) x 5.0 in (127 mm) x 5.0 in (127 mm).
• Weight: 0 lbs 9.6 oz (0.3 kg).
• Compatibility: Designed for use with GE Fanuc Series 90-30 PLC systems.
