Emerson VE4003S2B9 KJ3223X1-EA1 DeltaV Analog Input Card 16 Channel

The Emerson VE4003S2B9 KJ3223X1-EA1 is a 16-channel analog input card designed for the DeltaV distributed control system (DCS). It is specifically engineered to interface with multiple analog signals from field devices such as transmitters and sensors, ensuring accurate and reliable data acquisition for process monitoring and control.

This module supports various input signal types, including current and voltage, and provides advanced diagnostic capabilities for detecting abnormal conditions. With high-resolution conversion and noise immunity, it delivers consistent and precise measurements, contributing to operational efficiency in industrial automation systems.

Technical Specifications

Product Applications

• Oil and Gas: Monitoring flow, pressure, and temperature transmitters.

• Petrochemical Plants: Capturing continuous analog signals for precise process control.

• Power Generation: Acquiring sensor data from turbines, boilers, and environmental systems.

• Pharmaceutical: Ensuring compliance with strict process monitoring standards.

• Water and Wastewater: Supervising pumping stations and treatment processes.

Product Advantages

• High Accuracy: 16-bit resolution ensures precise signal conversion.

• Wide Signal Compatibility: Handles multiple standard analog input ranges.

• Enhanced Diagnostics: Supports open wire detection and fault identification.

• Robust Isolation: Electrical isolation reduces interference and enhances system reliability.

• Scalability: Easily integrates with other DeltaV cards for expanded capacity.

• Reliability: Designed for continuous operation in harsh industrial environments.

FAQ

Q1: What is the resolution of the Emerson VE4003S2B9 KJ3223X1-EA1 input card?

A1: The card provides 16-bit resolution for precise measurement of analog signals.

Q2: Does this module support HART-enabled devices?

A2: Yes, it can be used with HART-compatible field instruments for enhanced diagnostics.

Q3: What type of isolation is provided in this module?

A3: It features channel-to-bus and channel-to-ground isolation for improved safety and accuracy.

Q4: How many analog signals can this card handle simultaneously?

A4: The module can manage up to 16 independent analog input signals at the same time.

Q5: What diagnostic features are available?

A5: It supports channel diagnostics such as open wire detection, fault reporting, and signal status monitoring.

Q6: What is the typical input impedance of the module?

A6: The card offers high input impedance, ensuring minimal signal loading.

Q7: Is this module hot-swappable within the DeltaV system?

A7: Yes, it is designed for hot-swapping, allowing maintenance without system shutdown.

Q8: What types of analog input ranges are supported?

A8: It supports 4–20 mA, 0–5 V, 1–5 V, and other standard analog ranges.

Q9: How does the card handle signal noise?

A9: Built-in filtering and isolation features provide effective noise immunity.

Q10: Can this card be used in redundant configurations?

A10: Yes, it is fully compatible with redundant DeltaV configurations for high availability.
