The ABB AO810V2 Analog Output module excels in delivering exceptional performance and precision in various industrial applications. Equipped with advanced features and ensuring reliable operation, this module serves as a key component in control systems.

Features

• High Precision: The module provides precise analog output signals, enabling accurate control.
• Multiple Channels: It supports up to 8 channels, allowing for flexible system configuration.
• Wide Output Range: The output current range can be set from 0 to 20 mA or 4 to 20 mA.
• Robust Isolation: Each channel features groupwise isolation from ground, ensuring reliable and safe operation.
• Diagnostics: Front LED indicators offer valuable information about module status and fault conditions.

Applications

The AO810V2 module finds extensive application across various industrial fields:

• Process control systems
• Machine control and automation
• Robotics
• Industrial monitoring and measurement

Technical Specifications

• Number of Channels: 8
• Resolution: 14 bits
• Output Current Range: 0 to 20 mA or 4 to 20 mA
• Isolation: Groupwise isolation from ground
• Under/Over Range: – / +15%
• Diagnostics: Front LED’s indicate fault, run, warning, and OSP supervision

Benefits

The AO810V2 Analog Output module offers several advantages:

• Enhanced Control: Its high precision ensures accurate control over output signals.
• Reliable Performance: The module’s robust design and diagnostics enable efficient monitoring and fault detection.
• Easy Integration: It seamlessly integrates with control systems and devices.
• Versatile Application: The module proves suitable for various industrial sectors, providing flexibility and adaptability.

Conclusion

The ABB AO810V2 Analog Output module stands as a reliable and versatile solution for precise control in industrial applications. With its advanced features, multiple channels, and wide output range, it ensures enhanced performance and accuracy. Whether employed in process control, automation, or robotics, the AO810V2 module proves to be a valuable component delivering optimal results.

FAQs

Q: What is the resolution of the AO810V2 Analog Output module?

A: The AO810V2 module has a resolution of 14 bits, providing high precision for accurate control.

Q: What is the output current range of the AO810V2 module?

A: The AO810V2 module supports an output current range of 0 to 20 mA or 4 to 20 mA, allowing for flexible control options.

Q: Is the AO810V2 module isolated from ground?

A: Yes, each channel of the AO810V2 module is groupwise isolated from ground, ensuring reliable and safe operation.

Q: What are the diagnostic features of the AO810V2 module?

A: The AO810V2 module includes front LED indicators for fault, run, warning, and OSP supervision, providing valuable diagnostic information.

Q: Which control systems are compatible with the AO810V2 module?

A: The AO810V2 module is compatible with MTU TU810, TU812, TU814, TU830, and TU833, offering seamless integration with these control systems.
